[Supply] Original Chips TPS563201DDCR (TI) 3A, Synchronous Step-Down Converter

Shenzhen Mingjiada Electronics Co., Ltd.——Long term supply of TI (TPS563201DDCR) 4.5V to 17V input voltage, 3A output current, synchronous buck converter with Eco-mode.

Model Number: TPS563201DDCR

Package: SOT-23-6

Type: Synchronous Buck Converter

TPS563201DDCR Product Diagram:

Product Description Details

The TPS563201DDCR is a highly integrated synchronous step-down (Swift™) DC/DC converter. The TPS563201DDCR is optimised for space-constrained applications, and its compact SOT-23-6 (DDC) package makes it ideal for scenarios where on-board space is at a premium.The TPS563201DDCR integrates both high-side and low-side power MOSFETs internally to minimise external component count. The TPS563201DDCR integrates both high-side and low-side power MOSFETs internally, minimising the number of external components and reducing overall solution cost and board area. It is designed to provide high efficiency, excellent load transient response and stable output voltage.

TPS563201DDCR Key Specifications:

Input Voltage Range (VIN): 3.0V to 17V (up to 21V)

Output Voltage Range (VOUT): 0.8V to 7.0V (adjustable with external resistor divider)

Continuous Output Current (IOUT): Up to 3A

Switching Frequency: 570kHz (Typical) Optimised Efficiency vs. Balance

Efficiency: Up to 95% (typical, depending on VIN, VOUT, IOUT conditions)

Reference Voltage Accuracy: ±1% (25°C)

Operating Junction Temperature Range: -40°C to +150°C

Package: SOT-23-6

Critical Protections:

Overcurrent Protection (Hiccup Mode)

Thermal Shutdown Protection

Undervoltage Lockout Protection (UVLO)

TPS563201DDCR Applications:

Digital TV Power Supplies

HD Blu-ray™ Disc Players

Networked Home Terminals

Digital Set-Top Boxes (STBs)

Security Surveillance

The TPS563201DDCR is a 3A synchronous step-down converter with excellent performance, easy design, and very good price/performance ratio. Mingjiada Electronics has been supplying original TI (TPS563201DDCR) Synchronous Buck Converter for a long time. For more information about TPS563201DDCR or to inquire about pricing, please contact Mingjiada Electronics at:
