Shenzhen Mingjiada Electronics Co., Ltd. supplies the 5CGTFD5C5F23C7N, a high-performance FPGA from Intels Cyclone V GT series. The following is a detailed description of the product:1. Product Overview The 5CGTFD5C5F23C7N is an Intel Cyclone V GT se…

Shenzhen Mingjiada Electronics Co., Ltd. supplies the 5CGTFD5C5F23C7N, a high-performance FPGA from Intel's Cyclone V GT series. The following is a detailed description of the product:

1. Product Overview

The 5CGTFD5C5F23C7N is an Intel Cyclone® V GT series FPGA, manufactured using a 28nm low-power process, and features high-speed transceivers and a hard-core memory controller, making it ideal for high-bandwidth, low-cost design requirements. The device offers 77,000 logic elements (LE) and 240 I/O pins, supporting a data transfer rate of 6.144 Gbps, and is widely used in industrial automation, wireless communication, automotive electronics, and other fields.

2. Key Features

(1) High-Performance Logic Architecture

77,000 logic elements (LE) support complex digital logic designs.

2,908 logic array blocks (LABs) optimise resource utilisation.

6 high-speed transceivers support protocols such as PCIe Gen2, Serial RapidIO, and 10GbE.

(2) High-Speed Data Interfaces

6.144 Gbps transceivers are suitable for wireless base stations and data centre interconnections.

LVDS, LVTTL, and LVCMOS I/O are compatible with multiple voltage standards.

Hardcore DDR3 memory controller, enhancing storage access efficiency.

(3) Low-power design

1.1V core voltage, optimising dynamic power consumption.

28nm low-power process, suitable for portable devices.

(4) Rich storage resources

4.884 Mbit embedded RAM (EBR), supporting efficient data caching.

424 kbit distributed RAM, suitable for high-speed data processing.

(5) Industrial-grade reliability

Operating temperature: 0°C to +85°C, suitable for harsh environments.

AEC-Q100 certified (select models), compliant with automotive electronics standards.

3. Technical specifications

Logic units (LE): 77,000

Logic array blocks (LAB): 2,908

I/O count: 240

Transceiver rate: 6.144 Gbps

Embedded RAM: 4.884 Mbit

Core voltage: 1.1V

Package: FBGA-484

Operating temperature: 0°C to +85°C

4. Typical Applications

Industrial automation: PLC control, motor drive, HMI systems.

Wireless communication: 5G base stations, remote radio units (RRU).

Automotive electronics: ADAS, in-vehicle infotainment systems (IVI).

Consumer electronics: Smart TVs, high-definition video processing.

5. Supply Information

Mingjiada Electronics offers the 5CGTFD5C5F23C7N in stock, with genuine factory-direct products guaranteed, and supports fast delivery within 1-3 days.

5CGTFD5C5F23C7N (1).jpg
