[Supply] AD7490BCPZ (ADI) 12-Bit Analog To Digital Converter With Sequencer

Shenzhen Mingjiada Electronics Co., Ltd.——Long-term supply of ADI (AD7490BCPZ) 12-bit high-speed, low-power, 16-channel, successive-approximation ADC. operates from a single power supply with a supply voltage of 2.7 V to 5.25 V, and has a maximum throughput of up to 1 MSPS. the device has a built-in low-noise, The device includes a low-noise, wide-bandwidth sample-and-hold amplifier that can handle input frequencies above 1 MHz.

Product Details:

Model: AD7490BCPZ

Package: LFCSP-32

Type: 12-bit analogue-to-digital converter

Product Diagram:

The AD7490BCPZ uses advanced design techniques to achieve very low power consumption at high throughput rates. The AD7490BCPZ consumes only 1.8 mA at the highest throughput with a 3 V supply and 2.5 mA with a 5 V supply.The AD7490BCPZ features 16 single-ended analogue inputs with channel sequencers, which can be pre-programmed to select the order in which the channels are converted.

AD7490BCPZ Product Features:

High throughput rate: 1 MSPS

Nominal voltage (VDD): 2.7 V to 5.25 V

Low power consumption at maximum throughput

5.4 mW maximum (870 kSPS, 3 V supply)

12.5 mW maximum (1 MSPS, 5 V supply)

16 (single-ended) inputs with sequencers

Wide input bandwidth: 69.5 dB SNR (50 kHz input frequency) Flexible power consumption. kHz input frequency)

Flexible power/serial clock speed management

No pipeline delays

High-speed serial interface, SPI/QSPI™/MICROWIRE™/ DSP-compatible

Full shutdown mode: 0.5 μA (max)

32-pin LFCSP package

AD7490BCPZ Applications:

Multi-channel system monitoring

Battery-powered equipment

Power line monitoring

Data acquisition, instrumentation and process control

【Mingjiada Electronics】Long-term supply of ADI (AD7490BCPZ) 16-channel, 1 MSPS, 12-bit ADC converter with sequencer, for more information about AD7490BCPZ products or to consult the price, welcome to contact Mingjiada Electronics.
