[Qorvo] QPC1030D 2GHz to 18GHz High Power SPST Switch

[Qorvo] QPC1030D 2GHz to 18GHz High Power SPST Switch

Source:our siteTime:2024-04-11Views:

Shenzhen Mingjiada Electronics Co., Ltd. [Qorvo] QPC1030D 2GHz to 18GHz High Power SPST SwitchProduct DescriptionQPC1030D is a single-pole, single-throw (SPST) reflective switch fabricated on Qorvos QGaN15 0.15um GaN on SiC production process. Operati…

Shenzhen Mingjiada Electronics Co., Ltd. [Qorvo] QPC1030D 2GHz to 18GHz High Power SPST Switch


Product Description

QPC1030D is a single-pole, single-throw (SPST) reflective switch fabricated on Qorvo's QGaN15 0.15um GaN on SiC production process. Operating from 2 to 18 GHz, the QPC1030D typically provides up to 20W input power handling at control voltages of 0/-40 V. This switch maintains low insertion loss of 1.3 dB or less, and high isolation of 30 dB typical. The QPC1030D performance allows it to be used in a variety of applications across commercial, low and high power.


Key Features

Frequency Range: 2 to 18 GHz

SPST

Input Power: 20 W

Insertion Loss: 0.5 dB @ 10GHz Typical

Isolation: >25 dB

Switching Speed: < 170 ns

Control Voltage: 0/-45V

Dimensions: 1.12 x 1.62 x 0.10 mm


Typical Applications

Radar

Communications

Electronic Warfare


If you have a requirement, please call Mr. Chen for advice at:

Tel: +86 13410018555

E-mail: sales@hkmjd.com

Home page URL: www.hkmjd.com
