Multimode SoC QCA-4024-0-68CMQFN-TR-0D-0 Supports Bluetooth 5 and integrated IEEE 802.15.4

Source:our siteTime:2024-03-27Views:

Shenzhen Mingjiada Electronics Co., Ltd. offers System-on-Chip QCA-4024-0-68CMQFN-TR-0D-0 Multi-mode smart connectivity solution integrating IEEE 802.15.4 and Bluetooth.OverviewThe QCA4024 SoC is a multi-mode system-on-chip that supports Bluetooth 5 a…

Shenzhen Mingjiada Electronics Co., Ltd. offers System-on-Chip QCA-4024-0-68CMQFN-TR-0D-0 Multi-mode smart connectivity solution integrating IEEE 802.15.4 and Bluetooth.

Overview

The QCA4024 SoC is a multi-mode system-on-chip that supports Bluetooth 5 and 802.15.4 based technologies including Zigbee and Thread.

This low-power SOC integrates a Cortex M4F for application processing and a Cortex M0 for network stack processing and is designed to enable highly concurrent multi-radio solutions.

Qualcomm Technologies' QCA4020 SDK comes pre-integrated with support for advanced security features and mesh networking. The solution complements a portion of the portfolio beyond IoT devices to address the needs of multiple industries.

QCA4024 Block Diagram


Specification

LR-WPAN

Protocol: Zigbee, Threading

CPU

Name: Arm® Cortex®-M4F Processor, Arm® Cortex®-M0 Processor

Clock frequency: up to 128 MHz

Wi-Fi

Security: WPS WPS

Bluetooth

Specification version: Bluetooth® 5.0

Connection Technology: Bluetooth Low Power

Topology: Qualcomm Bluetooth® Mesh Technology

Security: Qualcomm® Trusted Execution Environment (TEE)

Features: Qualcomm® Trusted Execution Environment (TEE), secure boot, secure storage, application-level security, true random number generator, hardware-based encryption engine, key configuration security, software image encryption

Memory

Density: At least 300 kB

Interfaces

Supported interfaces: PWM, I²S, QSPI, I²C, GPIO, UART, SPI, SDIO 2.0, ADC1

Package

Type: QFN

Pinout: 68 pins

Size: 8 × 8 mm

Pitch: 0.9 mm
