In the field of modern high-speed communication and data centre, there is a growing demand for high-bandwidth, high-reliability connectivity solutions.

Shenzhen Mingjiada Electronics Co., Ltd. now has a stable supply of Amphenol 10128494-107500ULF ExaMEZZ® mezzanine connectors, which provide excellent connectivity solutions for high-speed signal transmission.

Product Description

The Amphenol 10128494-107500ULF ExaMEZZ® mezzanine connector is a high-performance, high-speed connector designed to meet the demand for high bandwidth in data centres, communication equipment, servers and high-end computing applications. Featuring an innovative ‘pinless’ design with 25 rows, 4 pairs, 350 contacts, and a plug height of 7.5mm, the connector supports high-speed signal transmission at 56Gb/s and meets the industry's requirements for higher bandwidth applications.

Product Features

High-speed transmission capability: Supports 56Gb/s high-speed signal transmission to meet the needs of high data rate applications.

Optimised Signal Integrity: The bundle-to-beam contact interface minimises residual short cuts to improve signal integrity performance, resulting in low crosstalk noise and low insertion loss.

Low insertion force: Provides very low insertion force while maintaining excellent contact normal force, ensuring connection stability and reliability.

High-density design: Miniaturised design enables more signal transmission channels per unit space, improving system integration.

Strong compatibility: Compatible with ExaMEZZ® connector system, convenient for upgrading and expanding in the existing system.

Model No.: 10128494-107500ULF

Manufacturer: Amphenol

Product Category: Board-to-Board and Mezzanine Connectors

Number of Positions: 350 Position

Pitch: 2 mm (0.079 in)

Termination Type: Press Fit

Mounting Angle: Vertical

Stacking height: 15 mm, 19 mm, 20 mm, 27 mm, 30 mm, 35 mm

Contact Material: Copper Alloy

Housing Material: Thermoplastic (TP)
