[LTC5586IUH] : 6GHz high linearity I/Q demodulator with wideband IF amplifier

Its core features include:

Operating frequencies from 300MHz to 6GHz

Wide IF bandwidth: DC to 1GHz (-1dB bandwidth)

High mixer IIP3:30dBm at 1.9GHz

High total OIP3:40dBm at 1.9GHz

High total OIP2:74dBm at 1.9GHz

User adjustable OIP2 up to 80dBm

User adjustable mirror frequency suppression up to 60dB

User adjustable DC offset zero

Serial interface

Power conversion gain: 7.7dB at 1.9GHz

31dB RF attenuator with 1dB step size

RF switch with 40dB isolation at 1.9GHz

Single-ended RF input with on-chip transformer

IF amplifier gain adjustable (in 8 stages)

Operating temperature range (TC) : -40 °C to 105°C

32 pin 5mm x 5mm QFN package

These characteristics make the LTC5586IUH suitable for demodulation of wideband wide signals, especially in digital predistortion (DPD) applications.

Product details

The LTC5586IUH is a direct conversion quadrature demodulator optimized for high linearity zero IF and low IF receiver applications in the frequency range from 300MHz to 6GHz. The very wide IF bandwidth (over 1GHz) makes the LTC5586IUH particularly suitable for demodulation of very wideband wide signals, especially in digital predistortion (DPD) applications.

The LTC5586IUH's excellent dynamic range makes the device suitable for demanding infrastructure direct conversion applications. The proprietary technology used within the LTC5586IUH provides the ability to optimize OIP2 to 80dBm and achieve mirror frequency rejection better than 60dB. The DC offset control function provides zeroing of the DC offset at the A/D converter input, thereby optimizing the dynamic range of a true zero IF receiver with a DC coupled IF signal path. Broadband RF and LO input ports enable coverage of all major wireless infrastructure bands with a single device.

The LTC5586IUH's IF output is designed to interface directly with most common A/D converter input interfaces. The device's high OIP3 and high conversion gain eliminate the need for additional amplifiers in the IF signal channel.

Application field

The LTC5586IUH is suitable for the following application scenarios:

4G and 5G base station receivers

Broadband DPD receiver

Point-to-point broadband radio equipment

High linearity direct conversion I/Q receiver

Mirror frequency suppression receiver

In addition, the specifications of the LTC5586IUH include:

Functions: Demodulator, amplifier

LO frequency: 300MHz ~ 6GHz

Radio frequency: 300MHz ~ 6GHz

P1dB: 12.5dBm

Gain: 9.2dB

Noise factor: 31dB

Current - Power supply: 440 mA

Voltage - Power supply: 5V

Mounting type: Surface mount type

Device package: 32-QFN (5x5)

Contact us

For [LTC5586IUH Demodulator] samples or purchase inquiries, you can contact Mingjiada Electronics by visiting the official website www.hkmjd.com!
