Maxim MAX4715EXK Low Voltage Single-Supply SPST Analog Switches

As a leading supplier of electronic components in the industry, Shenzhen Mingjiada Electronics Co., Ltd. supplies Maxim MAX4715EXK Low Voltage Single Supply SPST (Single Pole Single Throw) Analogue Switch from stock. With its ultra-low on-resistance, wide operating voltage range and miniature package, this MAX4715EXK high-performance analogue switch is ideal for portable devices, test and measurement instruments and communication systems.

Product Description Of MAX4715EXK

MAX4715EXK is low on-resistance, low-voltage, single-pole/single-throw (SPST) analog switches that operate from a +1.6V to +3.6V single supply. The MAX4715EXK is normally open (NO), it have fast switching speeds (tON = 18ns max, tOFF = 12ns max).

When powered from a +3V supply, the MAX4715EXK offer 0.4Ω max on-resistance (RON) with 0.1Ω max RON flatness. Their digital logic inputs are +1.8V CMOS compatible when using a single +3V supply.

MAX4715EXK is pin compatible with the MAX4594. The MAX4715EXK is available in SC70-5 packages.

Specification Of MAX4715EXK

Product Category: Analog Switch ICs

Mounting Style: SMD/SMT

Package / Case: SC-70-5

Number of Channels: 1 Channel

Configuration: 1 x SPDT

On Resistance - Max: 400 mOhms

Supply Voltage - Min: 1.6 V

Supply Voltage - Max: 3.6 V

On Time - Max: 18 ns

Off Time - Max: 12 ns

Minimum Operating Temperature: - 40 ℃

Maximum Operating Temperature: + 85 ℃

Pd - Power Dissipation: 247 mW

Product Type: Analog Switch ICs

Subcategory: Switch ICs

Supply Current - Max: 200 nA

Supply Type: Single Supply

Switch Continuous Current: 300 mA

Features Of MAX4715EXK

Low RON

- 0.4Ω max (+3V Supply)

- 1.2Ω max (+1.8V Supply)

0.1Ωtryi max RON Flatness (+3V Supply)

+1.6V to +3.6V Single-Supply Operation

Available in 5-Pin SC70 Packages

Fast Switching: tON = 18ns max, tOFF = 12ns max

+1.8V CMOS Logic Compatible (+3V Supply)

MAX4715EXK Key Performance Parameters:

Ultra-low on-resistance: With a typical value of only 0.4 ohms (0.5 ohms maximum), the MAX4715EXK is a leader in its class, significantly reducing signal path losses.

Fast switching speed: MAX4715EXK's turn-on time (Ton) of up to 18ns, turn-off time (Toff) of up to 12ns, to meet the needs of high-speed signal switching

Extremely low power consumption: MAX4715EXK quiescent current of only 40nA, significantly extending battery life

Wide operating temperature range: -40°C to +85°C, MAX4715EXK to adapt to a variety of harsh environments

Superior Signal Integrity: The MAX4715EXK has excellent channel-to-channel matching (ΔRon) and low crosstalk to ensure signal transmission quality.

The device is available in an ultra-compact SC-70-5 (SOT-353) package measuring only 2.0mm x 2.1mm x 0.9mm, making it ideal for space-constrained applications.MAX4715EXK is RoHS-compliant, lead-free, and environmentally friendly, which fully meets the environmental requirements of modern electronics.

Applications Of MAX4715EXK

1. Portable electronic devices

Audio signal routing in smartphones and tablets

Sensor signal switching in wearable devices

Analogue front-end design for portable medical monitoring devices

2. Test and Measurement Instruments

Signal Multiplexing in Automatic Test Equipment (ATE)

Channel Selection for Data Acquisition Systems

Range Switching for Precision Measuring Instruments

3. Communication Systems

RF signal switching in base station equipment

Gain control in fibre optic communication systems

Configuration switching in software-defined radio (SDR)

4. Industrial control systems

Analogue input selection for PLC modules

Signal conditioning in process control equipment

Sensor interfaces for industrial automation systems

5. Consumer Electronics

Input selection for HDTVs and monitors

Audio/video switching for home theatre systems

Signal processing for digital cameras and camcorders
