Shenzhen Mingjiada Electronics Co., Ltd. supplies and acquires Microchip Ethernet IC (324-BGA) VSC7435XMT 6-Port Carrier Ethernet Switch with 2 Integrated Cu PHYs and DPLLs

VSC7435XMT Device Description:

The VSC7435 Serval-TE™ Carrier Ethernet Switch targets IP edge demarcation and access devices for enterprise and mobile backhaul services.The VSC7435 is based on the Virtualised Service-Aware Architecture (ViSAA™), a silicon implementation that delivers unparalleled Service Edge and Carrier Ethernet (CE) networking capabilities. ViSAA enables wire-speed performance for even the most feature-rich Carrier Ethernet services, and the VSC7435 also integrates VeriTime™, Microsemi's patent-pending timing technology, which provides the industry's most accurate implementation of IEEE 1588v2 timing to meet today's LTE/LTE-A requirements.

The VSC7435 switch includes four 10/100/1000 Mbps ports (up to two copper ports) and two 10/100/1000/2500 Mbps ports. The integrated DPLL reduces BOM costs, simplifies system design, and provides proven interoperability between the switch and the DPLL. The VSC7435 offers a rich set of Carrier Ethernet switching features such as hierarchical QoS, hardware-based OAM (Ethernet and MPLS/MPLS-TP) and SAM, protection switching, synchronous Ethernet, and an integrated EEC/PEC DPLL controller. DPLL controller.The VSC7435 delivers MEF CE 2.0 EVC with Provider Bridging (Q-in-Q) and MPLS/MPLS-TP technologies.The Versatile Content-Aware Processor (VCAP™) architecture is scalable and flexible for security applications. It features advanced ingress and egress TCAM classification. Per EVC features include a rich set of statistics, OAM for end-to-end performance monitoring, and dual-rate policing and shaping.

IPv4/IPv6 Layer 3 (L3) routing and IPv4/IPv6 Layer 3 multicast multicast grouping are supported. l3 security features include source guard and unicast reverse path forwarding (uRFP) tasks.

The device includes a powerful 500 MHz MIPS-24KEc CPU for full management of the switch and advanced Carrier Ethernet applications.

The VSC7435 Serval-TE™ device is a 9 Gbps Carrier Ethernet switch with up to six ports that supports the following major port configurations:

- 4 × 1G SGMII ports + 2 × 2.5G SGMII ports

- 6 × 1G SGMII ports

- Two of the 1G SGMII ports are dual-media ports with a choice of 1G SGMII or 1G CuPHY.

In addition, the device supports one 10/100/1000 Mbps SGMII/SerDes Node Processor Interface (NPI) Ethernet port.

Recycling specific process:

1. You will make a simple classification of the backlog of IC/module inventory to determine the model, brand, production date, quantity, etc..

2. Please send the inventory list to our evaluation team by fax or email.

3.Wait for the company's professionals to make a purchase offer, after reaching an agreement, both sides will discuss the specific transaction mode for delivery.

4. The company only recovers formal channels of supply, such as agents, traders, terminal factories, etc., do not accept not formal channels of supply.
