Overview

The MAX17510ATB is a low voltage, DDR linear voltage regulator with low cost and low voltage features. The product is suitable for scenarios requiring low voltage and DDR voltage regulation. The input voltage ranges from 1.1V to 3.6V, the output voltage ranges from 0.5V to 1.5V, and the maximum output current is 3A (typical) ‌. The MAX17510ATB regulator uses a separate 3.3V bias supply to power the control circuit and drive the internal n-channel MOSFETs.

The MAX17510ATB features current and temperature limiting to prevent damage to the linear regulator. In addition, the MAX17510ATB generates a power ready (PGOOD) signal indicating whether the output is in the regulated voltage range. At startup, PGOOD remains low until the output stabilizes at 2ms (typical value). Internal soft start limits the input surge current.

Due to its low cost, low voltage and high performance, the MAX17510ATB performs well in applications requiring low power consumption and stable voltage output. Its built-in N-channel MOSFETs further enhance its applicability in a variety of electronic devices.

Key Features

Wide input voltage range ‌ : MAX17510ATB supports 1.1V to 3.6V inputs, suitable for low voltage scenarios ‌.

Flexible output voltage ‌ : The MAX17510ATB can be adjusted from 0.5V to 1.5V to meet the requirements of low-voltage loads such as DDR memory ‌.

High current output capability ‌ : The MAX17510ATB integrates an n-channel MOSFET and supports 3A peak current (typical value). Suitable for dynamic load scenarios ‌.

Package and size ‌ : Save PCB space ‌ in 10-pin TDFN-EP package (3mm x 3mm).

Protection ‌ : The MAX17510ATB has built-in overcurrent protection, hot shutdown, and soft start functions to improve system reliability ‌.

Efficient control ‌ : The MAX17510ATB supports external reference input tracking, dynamically adjusts the output voltage, and ADAPTS to the DDR terminal bus for power supply ‌.

Low power design ‌ : low static current, support off mode, optimize energy efficiency ‌.

Application field

The DDR memory is terminated at ‌ : MAX17510ATB provides accurate terminal voltage for DDR1/2/3/4 and reduces signal reflection ‌.

Portable computing device ‌ : MAX17510ATB Low voltage power supply for chipset /RAM for laptop and desktop computers ‌.

Industrial control module ‌ : MAX17510ATB supports sensors and microcontrollers that require dynamic voltage regulation ‌.

GPU core power supply ‌ : meets the power supply requirements of Gpus with low voltage and high transient response ‌.

Communication equipment ‌ : MAX17510ATB provides stable low-voltage power supply ‌ for RF modules and base stations.
