Mingjiada Electronics: Supply AM3703CBPD100 (TI) 32-Bit itara™ ARM Microprocessors

Texas Instruments (TI) AM3703CBPD100: High-Performance 32-bit Arm Cortex-A8 Sitara Processor

1. Product Overview

The AM3703CBPD100 is an industrial-grade 32-bit microprocessor in the Texas Instruments (TI) Sitara™ family, designed on the ARM Cortex-A8 core. The processor integrates powerful computing capabilities, rich peripheral interfaces, and a power-efficient architecture optimised for embedded applications, such as industrial control, portable devices, and multimedia terminals. As one of the core models of the Sitara AM37x series, the AM3703CBPD100 delivers an excellent balance of real-time performance, power consumption and scalability.

2. AM3703CBPD100 Key Specifications

Core Architecture: 32-bit Arm Cortex-A8 @ 1GHz

Process: 65nm CMOS

Package: 176-Pin HLQFP (CBPD100 suffix "PD" stands for the package type)

Operating Temperature: Commercial Grade (0°C to 90°C) (CBPD100 suffix "CB" stands for the package type) CB" for temperature range)

Memory Support: 32-bit DDR2/DDR3 SDRAM controller up to 400MHz

On-chip Memory: 64KB L1 Cache (32KB I-Cache + 32KB D-Cache) + 256KB L2 Cache

Power Management: Integrated SmartReflex™ Dynamic Voltage/Frequency Regulation Technology for multi-level power management. Power Management: Integrated SmartReflex™ Dynamic Voltage/Frequency Regulation Technology with Multi-Level Power Mode Support

3. AM3703CBPD100 Core Features

High-performance computing capability

1GHz Cortex-A8 core supports superscalar execution and NEON™ SIMD instruction set for complex algorithm processing (e.g., audio/video codecs).

Hardware floating point unit (VFPv3) accelerates maths-intensive tasks.

Rich peripheral interfaces

Display subsystem: integrated LCD controller, supports WXGA (1366×768) resolution output.

Connectivity:

10/100 Mbps Ethernet MAC

USB 2.0 OTG + HS Host x2

MMC/SD/SDIO interfaces

Multi-channel SPI/I²C/UART

Expansion Bus: GPMC (General Purpose Memory Controller) Supports expansion of devices such as FPGA, NOR Flash, and so on.

4. AM3703CBPD100 Application Scenarios

With its high performance and integration, AM3703CBPD100 is widely deployed in the following fields:

Industrial Automation:

PLC controller, HMI human-machine interface, and motion control module.

The AM3703CBPD100's real-time processing capability meets the needs of industrial communication protocols (e.g. EtherCAT, PROFINET).

Portable Medical Devices:

ultrasound imagers, portable monitors, relying on its low power consumption and multimedia processing capabilities.

Embedded vision systems:

machine vision inspection devices, smart cameras, accelerated image processing through the NEON engine.

Interactive terminals:

Self-service kiosks, POS systems, supporting multi-screen display and touch interaction.

【Mingjiada Electronics】Long-term supply of TI (AM3703CBPD100) 32-bit Arm Cortex-A8 Sitara processor, for more information about AM3703CBPD100 products, welcome to visit the official website of the Mingjiada Electronics (www.hkmjd.com) to view the details or ask the Mingjiada sales staff to get the price of the product.
