Linear Technology LTC3307AHV LQFN Package Synchronous Buck Switching Regulator

Linear Technology LTC3307AHV LQFN Package Synchronous Buck Switching Regulator

Source:本站Time:2022-07-04Views:

Supply and Acquisition of Linear Technology LTC3307AHV LQFN Synchronous Buck Switching Regulator Mingjiada sells brand new original, factory stock in stock, welcome to contact

Supply and Acquisition of Linear Technology LTC3307AHV LQFN Synchronous Buck Switching Regulator

Mingjiada sells brand new original, factory stock in stock, welcome to contact


The LTC3307A is a very small, high efficiency, low noise, monolithic synchronous 3A step-down DC/DC converter that operates from a 2.25V to 5.5V input supply. The regulator uses constant frequency peak current mode control at switching frequencies from 1MHz to 3MHz, with a minimum on-time as low as 22 ns, and enables fast transient response with small external components. The Silent Switcher architecture minimizes EMI emissions.


Feature

Pin Compatible with LTC3308(4A) and LTC3309(6A)

High Efficiency: 8mΩ NMOS, 31mΩ PMOS

Programmable frequency: 1MHz - 3MHz

Small inductors and capacitors

Peak Current Mode Control

22ns minimum on-time

Wide bandwidth, fast transient response

Silent Switcher® Architecture

Ultra low EMI emissions

Low Ripple Burst Mode® Operation with 40µA IQ

Safe to withstand inductor saturation under overload conditions

VIN range: 2.25V to 5.5V

VOUT range: 0.5V to VIN

VOUT accuracy: ±1% (full temperature range)

Accurate 400mV Enable Threshold, 1µA Shutdown

Power Good, Internal Compensation and Soft Start

Thermally Enhanced 2mm x 2mm LQFN Package

AEC-Q100 certified for automotive applications


Application

Optical Network, Server, Telecom

Automotive, Industrial, Communication

Distributed DC Power System (POL)

FPGA, ASIC, microprocessor core power supply

battery powered system
