Product description

‌ADUC831BSZ is a fully integrated 247 kSPS data acquisition system that integrates a high-performance self-calibrating multi-channel 12-bit ADC, dual 12-bit Dacs, and a programmable 8-bit MCU. ‌ADUC831BSZ has an 8052 core processor, compatible with the 8051 instruction set, and 12 core clock cycles per machine cycle. The ADUC831BSZ combines 62 KB of non-volatile Flash/EE program memory, 4 KB of non-volatile Flash/EE data memory, 256 bytes of RAM, and 2 KB of expansion RAM on a single chip. In addition, the ADUC831BSZ features two 12-bit Dacs, a power monitor, and a bandgap amplifier ‌.

The ADUC831BSZ is rated for operating voltage from 3 V to 5 V over an extended industrial temperature range and is available in a 52-pin MQFP package.

The ADUC831BSZ is suitable for applications requiring high-precision data acquisition and control, such as precision instruments, intelligent sensors, laser power control for fiber optic networks, base station systems, transient capture systems, DAS and communication systems ‌.

Main characteristics

The ADUC831BSZ uses the 8052 core, is compatible with the 8051 instruction set, and supports the main frequency up to 16.77MHz (via PLL doubling) ‌.

It has 62KB of Flash program memory, 4KB of non-volatile data memory, 256 bytes of RAM and 2KB of expansion RAM‌.

Integrated 12-bit multi-channel ADC (up to 247kSPS sampling rate), dual 12-bit Dacs and rail-to-rail voltage output module ‌.

ADUC831BSZ built-in precision temperature sensor and bandgap reference voltage source, support self-calibration ‌,

The ADUC831BSZ supports I2C, SPI, UART communication, and integrates dual-channel PWM, watchdog timer, and power monitoring module ‌.

The ADUC831BSZ is available in a 52-pin MQFP package, operating voltage 4.75V - 5.25V, industrial grade temperature range (-40°C to +85°C) ‌.

Typical application field

1. ‌ Industrial Automation and Sensor system ‌ :

With an integrated 12-bit ADC (247kSPS sampling rate) and dual 12-bit DAC, the ADUC831BSZ is suitable for high-precision signal acquisition and closed-loop control of temperature and pressure sensors ‌.

Support I²C, SPI, UART communication interface, ADUC831BSZ can be connected to industrial fieldbus equipment ‌.

2. ‌ Optical communication and base station equipment ‌ :

For laser power modulation and fiber optic network signal processing, the ADUC831BSZ built-in PWM module supports high-speed signal output ‌.

Combined with DMA controller to realize multi-channel high-speed data capture, ADUC831BSZ is suitable for base station signal processing module ‌.

3, ‌ precision instruments and portable equipment ‌ :

Built-in precision temperature sensor and band-gap voltage reference, the ADUC831BSZ is suitable for low power consumption scenarios such as portable medical devices and environmental monitors ‌.
