Mingjiada Electronics——Supply [Infineon] IKW40N65H5 High Performance TRENCHSTOP™ IGBT Transistor

Infineon IKW40N65H5 supplied by Mingjiada Electronics is a high performance TRENCHSTOP™ series IGBT transistor designed for high speed hard switching applications. The following is a detailed description of the transistor IKW40N65H5:

1. IKW40N65H5 - Product Overview

Model Number: IKW40N65H5

Brand: Infineon

Series: TRENCHSTOP™ 5

Voltage Rating: 650V

Current Rating: 40A

Package Type: TO-247-3

Features: High speed switching, low loss, high reliability

2. IKW40N65H5 - Key Parameters

Collector-Emitter Voltage (Vces): 650V

Collector current (Ic): 40A (continuous)

Maximum power consumption (Ptot): 200W

Collector-emitter saturation voltage (Vce(sat)): 1.7V @ 20A, 25°C

Gate Threshold Voltage (Vge(th)): 5V

Switching frequency Up to 100kHz

Input capacitance (Cies): 1800pF

Output capacitance (Coes): 220pF

Reverse transfer capacitance (Cres): 60pF

Thermal resistance (Rth(j-c)): 0.5°C/W

Operating junction temperature (Tj): -55°C to 150°C

3. IKW40N65H5 - Product Features

High-speed hard-switching performance: Optimised for high-frequency switching applications and suitable for hard-switching topologies.

Low conduction loss: The IKW40N65H5 utilises TRENCHSTOP™ technology with Vce(sat) as low as 1.7V for improved efficiency.

Low switching losses: Optimised switching characteristics reduce energy loss during switching.

High reliability: Rugged design and excellent thermal performance for harsh operating environments.

Easy to drive: Standard 5V gate drive voltage, compatible with most drive circuits.

4. IKW40N65H5 - Benefits

High Efficiency: Low conduction and switching losses for high energy efficiency.

High power density: Compact TO-247 package for space-constrained designs.

Versatility: The IKW40N65H5 is suitable for a wide range of high power and high frequency applications.

Long life: Excellent thermal management and electrical characteristics ensure long term stable operation.

5. IKW40N65H5 - application areas

Motor drives.

Industrial motor drives

Household appliances (e.g. washing machines, refrigerator compressors)

Power conversion: Switching power supplies (SMPS)

Switch-mode power supplies (SMPS)

Uninterruptible Power Supplies (UPS)

Inverters.

Solar Inverters

Electric Vehicle Inverters

Other Applications: Welding Machines

Welding Machines

Induction heating

High Frequency Power Systems

Summary: Infineon IKW40N65H5

The Infineon IKW40N65H5 is a high performance 650V, 40A IGBT transistor with TRENCHSTOP™ technology for high speed switching, low loss, and high reliability. The IKW40N65H5 is widely used in motor drives, power converters, and inverters, and is ideal for high power and high frequency applications. The IKW40N65H5 is ideal for high power and high frequency applications. For more information about the IKW40N65H5, please contact Mingjiada Electronics for more information about the IKW40N65H5 or check the company's website (www.hkmjd.com).
