Supply (ST) STM32F091RBT6-Mainstream MCU based on ARM Cortex-M0 core

Supply (ST) STM32F091RBT6-Mainstream MCU based on ARM Cortex-M0 core

Source:our siteTime:2025-02-26Views: 12

The ‌STM32F091RBT6‌ microcontroller, supplied by Shenzhen Minjiada Electronics, is a 32-bit flash microcontroller based on the ARM Cortr-M0 core, designed to provide MCU users with a new development freedom ‌. The STM32F091RBT6 combines high perfor…

The ‌STM32F091RBT6‌ microcontroller, supplied by Shenzhen Minjiada Electronics, is a 32-bit flash microcontroller based on the ARM Cortr-M0 core, designed to provide MCU users with a new development freedom ‌. The STM32F091RBT6 combines high performance, real-time functionality, digital signal processing, low power and low voltage operation, connectivity, while maintaining a high degree of integration and ease of development ‌.


1. Performance advantage

‌ Core architecture ‌

‌STM32F091RBT6‌ The 32-bit Arm® Cortex®-M0 processor with a 48-mhz main frequency supports real-time data processing and is suitable for high response scenarios ‌1. Its instruction set optimization design takes into account efficiency and power consumption to meet the dual requirements of embedded systems on performance and power consumption ‌.


‌ Storage configuration ‌

‌STM32F091RBT6‌ built-in 128~256 KB flash memory and 32 KB SRAM (with hardware parity), can store complex algorithm code and support dynamic data caching, to ensure the stability of multi-task ‌.


‌ Peripheral interface ‌

‌- Communication capability ‌ : Integrated 8 USART, 2 I²C, 2 SPI and 1 CAN interface, support industrial bus protocol, suitable for automation control and equipment interconnection ‌.

‌‌- Analog function ‌ : equipped with 12-bit ADC and dual-channel 12-bit DAC, it can accurately process sensor signals or generate analog outputs, such as temperature monitoring and motor drive scenarios ‌.

‌‌- Timing control ‌ : contains 7 16-bit timers and 1 32-bit timer, support PWM output, for precision timing control (such as LED dimming, motor speed regulation) ‌.


‌ Power management ‌

‌STM32F091RBT6‌ supports 2.0~ 3.6V wide voltage power supply, and integrates a variety of low power consumption modes, suitable for battery-powered portable devices ‌.


2. Application scenarios

‌ Industrial control ‌

‌STM32F091RBT6‌ CAN interface and high-speed communication capability make it become the core unit of PLC and industrial robot control, support multi-node real-time communication ‌. Its ADC/DAC module processes sensor data and drives actuators for automated production line monitoring ‌.


‌ Consumer electronics ‌

In smart home devices, ‌STM32F091RBT6‌ realizes backlight adjustment, motor control (such as intelligent fan speed regulation) through PWM, and prolonging device life through low power consumption mode ‌.


‌ communication equipment ‌

The USART and SPI interfaces of the chip can build a gateway device to realize serial port to WiFi/ Bluetooth communication, which is applied to the data acquisition and transmission of Internet of Things terminal ‌.


‌ Medical equipment ‌

‌STM32F091RBT6‌ high precision ADC and hardware verification function, can be integrated in portable medical equipment (such as blood glucose meter, sphygmomanometer), to ensure the accuracy and reliability of signal acquisition ‌.


3. Summary

As a representative of high performance microcontroller, ‌STM32F091RBT6‌ with its 48MHz main frequency, multi-protocol communication interface and flexible power management, has shown wide applicability in industrial, consumer, medical and other fields. The stable supply and technical support of Mingjiada Electronics further promote the large-scale application of ‌STM32F091RBT6‌ in embedded systems ‌.
