Sell Qualcomm Bluetooth IC QCC-3026-0-81WLNSP-TR-00-0 Entry-level Flash Bluetooth Audio SoCs

Sell Qualcomm Bluetooth IC QCC-3026-0-81WLNSP-TR-00-0 Entry-level Flash Bluetooth Audio SoCs

Source:our siteTime:2023-10-25Views:

Shenzhen Mingjiaoda Electronics Co., Ltd. new original sale Qualcomm Bluetooth IC QCC-3026-0-81WLNSP-TR-00-0 Entry-level flash Bluetooth audio SoC, designed for low power consumption.OverviewThe QCC3026 is an entry-level flash-programmable Bluetooth a…

Shenzhen Mingjiaoda Electronics Co., Ltd. new original sale Qualcomm Bluetooth IC QCC-3026-0-81WLNSP-TR-00-0 Entry-level flash Bluetooth audio SoC, designed for low power consumption.


Overview

The QCC3026 is an entry-level flash-programmable Bluetooth audio SoC based on an ultra-low-power architecture designed for feature-optimised compact Qualcomm TrueWireless™ earbuds.The QCC3026 is designed to provide our customers with a solution that helps to shorten development time and is cost-effective.


Specification

CPU

Architecture: 32-bit

Clock frequency: Up to 32 MHz

Function: Programmable CPU

DSP

Name: 1x Qualcomm® Kalimba™

Clock frequency: 1x 120 MHz

Data RAM: 256 kB

Programme RAM: 80 kB

Function Configurable DSP

Bluetooth

Specification version: Bluetooth® 5.0

Connectivity technologies: Bluetooth Low Power, Bluetooth Classic, Dual Mode Bluetooth

Topologies: Qualcomm TrueWireless™ Stereo Enhancement Technology, Qualcomm TrueWireless™ Technology, Qualcomm Broadcast Audio Technology

Classic Data Rate: 2 Mbps

Low Energy Features: Bluetooth® Low Energy Sensor Hubs

Audio

Support for Qualcomm® aptX™ audio technology: Qualcomm® aptX™ audio

Support for Qualcomm® cVc™ Echo Cancellation and Noise Suppression (ECNS) Technology: 2-microphone headset, 1-microphone headset, Qualcomm® cVc™ Echo Cancellation and Noise Suppression Technology

Voice Services

Digital Assistant Activation: Pushbutton

Power Consumption

Amperage: Less than 6 mA

Audio Playback Interface

Mode: Mono

Package

Type: WLCSP

Pinout: 81 pins

Size: 3.98 × 4.02 × 0.5 mm

Pitch: 0.4 mm
