Recycle Automotive High Precision Voltage Isolation Amplifier [ACPL-C87BT-000E]

Recycle Automotive High Precision Voltage Isolation Amplifier [ACPL-C87BT-000E]

Source:our siteTime:2025-02-12Views:

OverviewThe ACPL-C87BT-000E Automotive isolation amplifier uses superior optical coupling technology with sigma-delta (Σ−Δ) analog-to-digital converters, chopper-stabilized amplifiers, and a fully differential circuit topology to provide unmatched …

Overview

The ACPL-C87BT-000E Automotive isolation amplifier uses superior optical coupling technology with sigma-delta (Σ−Δ) analog-to-digital converters, chopper-stabilized amplifiers, and a fully differential circuit topology to provide unmatched isolation mode noise suppression, low offset, and high efficiency. High gain accuracy and stability The ACPL-C87BT (± 0.5% gain tolerance) is designed for high-precision DC voltage detection in electronic motor drivers, DC/DC and AC/DC converters, and battery monitoring systems. The ACPL-C87BT has a high input impedance and can operate at a full range of analog input voltages up to 2.46V. The shutdown function provides power saving and can be controlled by an external signal source, such as a microprocessor.


Features

Unity gain

± 0.5% (ACPL-C87BT) and 1% (ACPL-C87AT) gain tolerances @ 25 oC

25ppm/o C gain drift compared to temperature

-0.3 mV Input offset voltage

0.05% nonlinearity

Nominal input range 0 to 2V

100kHz bandwidth

Meets AEC-Q100 Level 1 test guidelines

Car operating temperature -40 to + 125°C

Turn-off function (active high)

15 kV /μs common mode suppression at V CM = 1000V

Compact surface mount Str etched SO-8 package

Global Safety Certification:

UL 1577 (5000 V RMS / 1 min.) And CSA

IEC/EN/DIN EN 60747-5-5 (TBD)


Applications

Automotive motor inverter DC bus voltage sensing

Automotive DC/DC converter voltage sensing

Automotive AC/DC (charger) DC output voltage sensing

Automotive battery voltage sensing

Temperature sensing isolation interface

Universal voltage sensing and monitoring
