Product Introduction:

The Marvell®Alaska®88E1512-A0-NNP2I000 device is a physical layer device that contains a 10/100/1000 Gb Ethernet transceiver. The transceiver implements the Ethernet physical layer portions of 1000BASE-T, 100BASE-TX, and 10BASE-T standards. It is manufactured in a standard digital CMOS process and contains all the active circuits needed to enable the physical layer functionality to send and receive data over standard CAT 5 unshielded twisted pair wires.

The device supports RGMII (Reduced Pin Count GMII) and SGMII for direct connection to MAC/Switch ports. SGMII can also be used on the media/line side to connect to SFP modules that support 1000BASE-X, 100BASE-FX and SGMII. It also supports copper/fiber automatic media applications with RGMII as the MAC interface. SGMII runs at 1.25 Gbps on a single differential pair, reducing the amount of power and I/O used on the MAC interface.

The device integrates the MDI terminal resistor into the PHY. This resistor integration simplifies board layout and reduces board costs by reducing the number of external components. The new Marvell® calibration resistor solution will meet and exceed the accuracy requirements of the IEEE 802.3 return loss specification.

Features

• Compliant with 10/100/1000BASE-T IEEE 802.3

• Multiple operating modes

• RGMII to copper

• SGMII to copper cable (88E1512/88E1514 device only)

• RGMII to Fiber /SGMII (88E1512 devices only)

• RGMII to Copper/Fiber /SGMII with automatic media detection (88E1512 devices only)

• Copper to Fiber (1000BASE-X) (88E1512/88E1514)

Four RGMII timing modes, including integrated delay - this eliminates the need to add wiring delay on the PCB

• Support for 1000BASE-X and 100BASE-FX and SGMII on fiber interfaces (88E1512 devices only)

• Support for LVCMOS I/O standards on RGMII

• Support Energy Efficient Ethernet (EEE) - compliant with IEEE802.3az-2010 standards

• EEE buffering

• Combined with EEE buffering, seamlessly supports traditional Macs

• Ultra-low power consumption

• Integrated MDI terminal resistor without passive components

• Integrated switching regulator

• Support green Ethernet

• Active power saving mode

• Energy Detect and Energy Detect+ Low power modes

• IEEE1588 version 2 timestamp

Synchronous Ethernet (SyncE) clock recovery

• Three loopback modes are used for diagnostics

• "Downshift" mode for two-pair cable installation

Fully integrated digital adaptive equalizer, echo canceller and crosstalk canceller

• Advanced digital baseline drift correction

• Automatic MDI/MDIX crossover at all operating speeds

• Automatic polarity correction

• Automatic negotiation according to IEEE 802.3 standard

• Software programmable LED mode, including LED testing

• MDC/XMDIO management interface

• CRC checker, packet counter

• Packet generation

• LAN Wake up (WOL) event detection

• Advanced Virtual Cable Tester ® (VCT™)

• Automatic calibration of MAC interface output

• Temperature sensor

• Single 3.3V power supply is supported when using internal switching regulators

• I/O pads are available at 1.8V, 2.5V or 3.3V

• Commercial and Industrial grades (88E1510 and 88E1512 only)

• 56-pin QFN 8 mm x 8 mm green package with EPAD
