Shenzhen Mingjiada Electronics Co., Ltd. (distributor of TI) TAS5711PHPR 20W Stereo, 8V to 26V, Digital Input, Open Loop Class D Audio Amplifier with EQ and DRC, 2.1 Channel Support

Product Details

The TAS5711PHPR is a 20W, highly efficient digital audio power amplifier for driving stereo bridged speakers. A serial data input allows processing of up to two discrete audio channels and seamless integration with most digital audio processors and MPEG decoders. The device accepts a wide range of input data and data rates. A fully programmable data path routes these channels to the internal speaker drivers.

The TAS5711PHPR is a pure I2S slave device, receiving all clocks from external sources. the TAS5711PHPR operates with a PWM carrier between a 384-kHz switching rate and a 352-kHz switching rate, depending on the input sampling rate. Oversampling is combined with a fourth-order noise shaper to provide flat background noise and an excellent dynamic range from 20 Hz to 20 kHz.

Product attributes

Product type: Audio amplifier

Class: Class-D

Output power: 20 W

Mounting Style: SMD/SMT

Type: 2.1-Channel Stereo

Package / Case: HTQFP-48

Audio - Load Impedance: 8 Ohms

THD + noise: 0.06 %

Supply voltage - max: 26 V

Supply voltage - min: 8 V

Min. operating temperature: 0 C

Maximum operating temperature: + 85 C

Features: 3D Support

Humidity sensitivity: Yes

Number of channels: 2 Channel

Operating supply current: 48 mA

Operating supply voltage: 3.3 V

Number of factory packs: 1000

Advantages

Up to 90% efficiency

Supports AD and BD filtering modes

S/N ratio: 106 dB, A-weighted

EQ: Speaker equalisation for improved audio performance

DRC: Dynamic range compression. Can be used as a power limiter. Enables

Speaker protection, easy listening, night mode listening.

Separate DRC for satellites and sub-channels

Automatic library switching: pre-loaded coefficients for different sample rates.

No need to write new coefficients to the part when the sample rate is changed.

Automatic detection: Automatic detection of sample rate changes. No need for

intervention of an external microprocessor

Only 3.3V and PVDD required

Applications

TVs

iPod™ docks

Audio bar
