Device overview:

The LCMXO3L-9400C-5BG484C MachXO3™FPGA is the smallest, lowest cost per I/O programmable platform designed to extend system functionality and bridge emerging connectivity interfaces through parallel and serial I/O. MachX03 simplifies the implementation of emerging connectivity interfaces MIPI, PCIe, and GbE, for example by matching advanced, small-footprint packages to on-chip resources.

This ultra-low-density FPGA offers a single programmable bridge that allows differentiated systems to be built using the latest components and interface standards. With advanced packaging technology solutions that eliminate bonding lines, achieve the lowest cost and higher I/O density in a smaller footprint, the MachXO3 series can be used in various market segments, including consumer, communications, compute, storage, industrial and automotive.

Features:

• Supports up to 9400 LUT and 384 I/O

• 1 ms instant start with background updates, interruptionless update I/O reconfiguration, dual boot error recovery

Optional 3.3/2.5V or low voltage 1.2V cores - including 9400 LUT device selection

• Non-volatile MachXO3L devices feature multiple programmable NVCM

MachXO3LF includes programmable flash and User Flash (UFM)

• Offers surprisingly small 2.50 mm x 2.50 mm WLCSP packages and BGA packages with pin spacing of 0.50 mm and 0.80 mm

LCMXO3L-9400C-5BG484C Technical parameters:

LAB/CLB number: 1175

Number of logical elements/units: 9400

Total RAM bits: 442368

Number of I/ OS: 384

Voltage - Power supply: 2.375V ~ 3.465V

Mounting type: Surface mount type

Operating temperature: 0°C ~ 85°C (TJ)

Package/housing: 484-LFBGA

Supplier Package: 484-CABGA (19x19)

Basic product number: LCMXO3
