[Supplied AI Processor] TDA4VL21HGAALZRQ1 for intelligent visual camera applications Automotive

[Supplied AI Processor] TDA4VL21HGAALZRQ1 for intelligent visual camera applications Automotive

Source:本站Time:2023-06-01Views:

Product details:The TDA4VL21HGAALZRQ1 (SoC) processor is based on the evolving Jacinto™ 7 architecture and is geared towards smart visual camera applications.The device provides high-performance computing for both traditional and deep learning algori…

Product details:

The TDA4VL21HGAALZRQ1 (SoC) processor is based on the evolving Jacinto™ 7 architecture and is geared towards smart visual camera applications.

The device provides high-performance computing for both traditional and deep learning algorithms with industry-leading power/performance ratios and a highly integrated system that provides scalability and lower cost for advanced visual camera applications. Key cores include next-generation DSPS with scalar and vector cores, dedicated deep learning and traditional algorithm accelerators, current Arm and GPU processors for general purpose computing, integrated next-generation imaging subsystems (ISPs), video codecs, and isolated MCU islands. All are protected by automotive grade safety and Security hardware accelerators.





TDA4VL21HGAALZRQ1 Technical parameters:

Number of I/ OS: 155

Architecture: DSP, MCU, MPU

Core processors: ARM® Cortex®-A72, ARM® Cortex®-R5F, C66x, C7x

Flash memory size: -

RAM size: 1.5MB

Peripheral: DMA, PWM, WDT

Connection capacity: MCAN, MMC/SD/SDIO, I²C, SPI, UART, USB

Speed: 2GHz, 1GHz, 1GHz

Main attributes: -

Operating temperature: -40°C ~ 125°C (TJ)

Package/case: 770-BFBGA, FCBGA

Supplier Device Package: 770-FCBGA (23x23)


Application:

Advanced Driver Assistance System (ADAS)

Machine vision

Industrial transportation

Retail automation

monitor


If necessary, please contact Mr. Chen:

Tel: +86 13410018555

Email: sales@hkmjd.com

Company homepage: www.hkmjd.com
