Product Overview:

The LE9541DUQCT Ringing SLIC device is a single channel device equivalent to channel 1 of the LE9540. It offers the same 6x6 40-pin QFN package as the ELE9540 for "dual" single channel or dual channel PCB designs. LE9551 also corresponds to a channel of LE9540. It offers small 4x5 28 pin QFN and is optimized for single channel applications. These devices provide battery feed and supervise voice loops found in short-loop cable applications. These devices are optimized to interface with Broadcom BCM338x or bcm339x family SoCs. Operation control and status reporting communicate via a serial interface with reset. These devices support broadband applications and GR909 testing.

Features：

• Optimized to work with BCM338x/BCM339xBroadcom SoCs for short loop residentialgateways

• Single Channel High Voltage Ringing SLIC that isfunctionally equivalent to one channel of theLe9540.

• Le9541 is available in a 6x6 40-pin QFN packagethat is "pin-to-pin" compatible with (channel 1 of)Le9540 which enables a dual one or two channelPCB Design.

• Le9551 is available in a 4x5 28-pin QFN that isoptimized for single channel applications

• High Voltage High Bandwidth Design Supports7-kHz Wide Band Applications

- Up to -145 V ringing battery Le9541/51D

- Up to -100 V ringing battery Le9541/51C

• Operation Control and Status Report throughSerial Interface with Reset

• Supports GR909 Testing

• DC Loop Closure/Ring Trip/Thermal Shut-down

• Loop Start, Ring Trip, and Ring-GroundDetections with Two Thresholds

• Thermal Shut down Protection with Hysteresis

• Test Load Switch Supports Integrated Test Algorithms

Featured Applications for LE9541DUQCT：

Broadband Gateway (non-DSL)

Broadband Home / CPE
