AXT426124 is a narrow pitch (0.4mm) pin header connector for board-to-board connections, utilising surface mount technology (SMD) with 26 pins (2 rows). Its compact design makes it suitable for space-constrained portable electronic devices.

AXT426124 Product Specifications

Manufacturer:    Panasonic

Product Type:    Board-to-Board and Interlayer Connectors

Number of Positions:    26 Position

Pitch:    0.4 mm (0.016 in)

Termination Type: Solder

Mounting Angle: Vertical

Current Rating: 300 mA

Voltage Rating: 60 V

Contact Plating: Gold

Contact Material: Copper Alloy

Housing Material: Liquid Crystal Polymer (LCP)

Series: P4S

Features and Overview

The AXT426124 belongs to Panasonic's P4S series of connectors, designed to meet the high-density interconnect requirements of compact portable electronic devices.

Compact Design: Its narrow 0.4 mm pitch and low board height (approximately 1.25 mm) make it ideal for applications such as mobile phones, digital still cameras (DSC), and digital video cameras (DVC).

High Reliability: Incorporates a centre strip contact design with solder retention features, ensuring secure connections during soldering and mating cycles. Some documentation references its ‘two-piece construction’.

Dual mating heights: This connector supports 1.5mm or 2.5mm mating stack heights, offering design flexibility.

Automation-friendly: Surface-mount type and tape-and-reel packaging facilitate automated placement for mass production.
