234206-E is a board-to-board connector manufactured by TE Connectivity, belonging to the ERNI SMC series. This connector employs SMD (Surface Mount Device) mounting, featuring 12 pins arranged in 2 rows with a pitch of 1.27mm. It is suitable for board-to-board connections in various electronic devices, offering high reliability and excellent electrical performance.

234206-E Specifications

Manufacturer: TE Connectivity

Product Type: Board-to-Board and Interlayer Connectors

Product: Connectors

Number of Positions: 12 Position

Pitch: 1.27 mm (0.05 in)

Number of Rows:    2 Row

Termination Type:    Solder

Mounting Angle:    Vertical

Stacking Height:    4.85 mm

Current Rating:    1.6 A

Maximum Data Rate:    3 Gbps

Minimum Operating Temperature:    -55°C

Maximum Operating Temperature:    +125°C

Contact Plating:    Gold

Contact Material:    Copper Alloy

Housing Material:    Liquid Crystal Polymer (LCP)

Series:    SMC 1.27mm

Application:    Board-to-Board

Data Rate:    3 Gbps

Flammability Rating:    UL 94 V-0

Insulation Resistance:    10 GOhms

Mounting Style:    Mounting Peg

Trademark:    SMC
