EKMC1603112 is a passive infrared (PIR) motion sensor belonging to the EKMC series, using a TO-5 package, suitable for human detection, security monitoring, smart lighting and other applications. The sensor has a long-distance detection capability of 12 metres and supports digital signal output, suitable for low-power, high-sensitivity scenarios.

EKMC1603112 Core Features

Long-range detection:

Maximum sensing distance: 12 metres (472 inches)

102° wide-angle detection range, covering a broader area

Digital output & low power consumption:

Output type: Digital signal (for direct reading by the MCU)

Operating current: 170 μA (low-power design)

Wide voltage supply: 3V to 6V power input, compatible with various system designs

Anti-interference design:

Black polyethylene lens for optimised infrared signal reception

Internal trigger to reduce false alarms

Industrial-grade reliability:

Operating temperature: -20°C to +60°C

Compliant with RoHS standards, lead-free and environmentally friendly

EKMC1603112 Product Attributes

Manufacturer: Panasonic

Product Type: Trigger Interface Motion Sensor and Position Sensor

Product: Motion Sensor

Sensing Distance: 12 m

Output Type: Digital

Operating Power Current: 170 uA

Power Voltage - Minimum: 3 V

Supply Voltage - Maximum:    6 V

Maximum Operating Temperature:    +60°C

Minimum Operating Temperature:    -20°C

Package/Enclosure:    TO-5

Mounting Style:    Through Hole

Features: Closed-loop sensing circuit, high signal-to-noise ratio

Supply Voltage:    5 V

Output Current:    100 uA
