The AQW210EHAX is a PhotoMOS™ series optocoupler relay launched by Panasonic Corporation, belonging to the solid state relay (SSR) category.

AQW210EHAX Features

High input/output isolation voltage, up to 5,000 V

Suitable for 2 Form A applications, as well as two

independent 1 Form A applications

Controls low-level analogue signals

High sensitivity and fast response

Maximum leakage current in low-level off state: 1 μA

AQW210EHAX Product Attributes

Manufacturer:    Panasonic

Product Type:    Solid-State Relay - PCB Mount

Mounting Style:    PCB Mount

Load Current Rating:    120 mA

Load Voltage Rating:    350 VAC, 350 VDC

Relay Contact Form:    2 Form A (DPST-NO)

Control Voltage Range:    1.25 VDC

Package/Enclosure:    SMD DIP-8

Output Type:    Photo MOSFET

Input Current:    50 mA

Minimum Operating Temperature:    -40°C

Maximum Operating Temperature:    +85°C

Length:    9.86 mm (0.388 in)

Width:    6.4 mm (0.252 in)

Height:    2.9 mm (0.114 in)

Series:    AQW

Contact Form:    DPST (2 Form A)

Input-to-Output Insulation Method:    Optocoupler

Insulation Voltage:    5 kV

Pd-Power Dissipation:    850 mW

AQW210EHAX Typical Applications

Modems

Telephone Equipment

Power Equipment

Security Equipment

Sensing Equipment
