W25Q16JVSSIQ is a high-performance, low-power NOR flash memory device offering 16Mbit (2M x 8-bit) storage capacity with data transfer via SPI interface. Supporting both two-wire and four-wire SPI operation, this chip significantly enhances data transfer rates, making it suitable for embedded applications requiring rapid data access.

W25Q16JVSSIQ Technical Specifications

Manufacturer:    Winbond

Product Type:    NOR Flash

Mounting Style:    SMD/SMT

Package / Case:    SOIC-8

Series:    W25Q16JV

Storage Capacity:    16 Mbit

Supply Voltage - Min:    2.7 V

Supply Voltage - Max:    3.6 V

Active Read Current (Max): 25 mA

Interface Type:    SPI

Maximum Clock Frequency:    133 MHz

Organisation:    2 M x 8

Data Bus Width:    8 bit

Timing Mode:    Synchronous

Minimum Operating Temperature:    -40°C

Maximum Operating Temperature:    +85°C

W25Q16JVSSIQ Product Features

High Performance: Supports clock frequencies up to 133 MHz, equivalent to 266 MHz and 532 MHz during dual-wire and quad-wire SPI operation respectively.

Low Power Consumption: Current draw as low as 1 µA in power-down mode.

Flexible Memory Architecture: Features unified 4 KB sectors with 32 KB/64 KB block erase capability.

High Reliability: Supports erase/program pause and resume functionality.

Security Features: Provides software and hardware write protection, one-time programmable (OTP) protection, 64-bit unique ID, and 3x256-byte security registers.

Compact Package: Utilises an 8-pin SOIC package, saving PCB space.

Application Scenarios

The W25Q16JVSSIQ is suitable for diverse application domains, including but not limited to:

Embedded Systems: Storing firmware, programmes, and data to ensure stable device operation.

Consumer Electronics: Such as smartphones and tablets, for storing system software and user data.

Industrial Control: Storing control programmes and operational data within industrial modules.

Automotive Electronics: Suitable for applications requiring high reliability and wide temperature range.
