The STM32G071G8U6N is a 32-bit ARM Cortex-M0+ microcontroller packaged in a 28-UFQFPN package, operating at a clock speed of 64 MHz. It is designed for low-power, cost-effective embedded applications such as the Internet of Things (IoT), industrial control, and consumer electronics. This chip belongs to the STM32G0 series, featuring 64 KB of Flash memory, 36 KB of RAM, and a rich set of peripheral interfaces, including USB, CAN, I2C, SPI, and UART, to meet the needs of various applications.

STM32G071G8U6N Technical Specifications

Core Architecture: ARM Cortex-M0+ (32-bit RISC)

Clock Speed: 64 MHz

Flash Storage: 64 KB

RAM: 36 KB

EEPROM: 2 KB

Operating Voltage: 1.71V to 3.6V

I/O Count: 26

Communication Interfaces: 2× UART, 2× SPI, 2× I2C, 1× USB 2.0, 1× CAN

ADC: 12-bit, 11 channels

DAC: 12-bit, 2 channels

Timers: 16-bit PWM, Watchdog Timer (WDT)

Operating Temperature: -40°C to +85°C

Package: 28-UFQFPN (4×4 mm)

STM32G071G8U6N Key Features

• High performance + low power consumption: M0+ core at 64 MHz, operating power consumption of 114 µA/MHz, standby mode at 400 nA

• Rich analogue features: high-speed ADC, dual DAC, comparators, internal voltage reference, suitable for sensor interfaces

• Compact size: 28-pin 4 mm × 4 mm, ideal for space-constrained designs

• Security features: Memory Protection Unit (MPU), hardware parity check, code protection

• Development ecosystem: STM32CubeMX & HAL/LL drivers, compatible with Arduino® Nano-compatible boards

STM32G071G8U6N Typical Applications

• Industrial control: PLCs, sensor nodes, motor drives

• Consumer electronics: smart home devices, wearable devices, electric toothbrushes

• Medical devices: portable monitors, blood glucose meters

• IoT: battery-powered IoT endpoints, smart meters, trackers
