The ACS732KLATR-20AB-T is a high-bandwidth, high-precision current sensor IC manufactured by Allegro MicroSystems, specifically designed for AC and DC current sensing in automotive, industrial, commercial, and communications systems. It employs differential Hall sensing technology to effectively suppress common-mode magnetic field interference, providing high-precision current measurement.

ACS732KLATR-20AB-T Product Features

High Bandwidth and Fast Response: Features a 1 MHz analogue output bandwidth and a fast response time of 210 ns, making it suitable for high-frequency switching applications.

High Isolation Performance: Utilises a SOIC-16 wide-body package to provide electrical isolation, making it suitable for high-voltage applications.

Low Noise and High Precision: Achieves industry-leading noise performance through proprietary amplifier and filter design, ensuring high-precision measurements.

Low Power Consumption and High Surge Current Withstand Capability: The main body resistance is only 1 mΩ, effectively reducing power consumption and enhancing surge current withstand capability.

Flexible Power Options: Supports 3.3 V and 5 V single-power-supply operation.

Factory Calibration: Sensitivity and static output voltage are calibrated at the factory to ensure high precision.

AEC-Q100 Certification: Complies with automotive-grade standards to ensure reliability in harsh environments.

ACS732KLATR-20AB-T Technical Specifications

Current Measurement Range: ±20A (bidirectional)

Output Type: Ratio-to-voltage (66mV/A)

Supply Voltage: 3.3V (3.14V to 3.46V)

Bandwidth: DC to 1MHz

Response Time: 700ns

Isolation Voltage: 3600V RMS

Package: 16-Pin SOIC-W (7.5mm wide)

Operating Temperature: -40°C to +125°C

ACS732KLATR-20AB-T Application Areas

Automotive Electronics: Chargers and DC-DC converters for electric vehicles (EV) and hybrid electric vehicles (HEV)

Industrial Control: Motor control, inverters, and switching power supplies

Communication Systems: High-frequency switching power supplies and inverters

Commercial Applications: High-precision current monitoring and control
