BT8969B5 is a high-performance Bluetooth audio SoC chip that adopts RISC-V architecture, supports Bluetooth 6.0 and BLE specifications, and is suitable for a variety of audio devices and smart application scenarios.

Model: BT8969B5

Type: Bluetooth Audio SoC (System-on-Chip)

Brand: Bluetrum

Process: 22nm low power consumption process

Main applications: TWS true wireless headphones, Bluetooth speakers, smart wearable devices

Bluetooth version: Supports Bluetooth 5.4 (including LE Audio)

Characteristics of BT8969B5

High-performance processor architecture: RISC-V 32-bit CPU (up to 125MHz) + HiFi 4 DSP (270MHz), supporting floating-point arithmetic (FPU).

Built-in 16Mbit Flash storage unit + 892KB RAM, supporting complex audio algorithms.

Bluetooth and audio performance: Supports LE Audio and LC3 codec, providing a wireless audio experience with lower latency and higher sound quality.

TX output power: + 9dBm (max), RX sensitivity:-94.5 dBm @ EDR/-95.5 dBm @ BLE.

Built-in 24bit DAC (signal-to-noise ratio 106dB) and 24bit ADC (signal-to-noise ratio 103dB) to support high-fidelity audio processing.

AI noise reduction and call optimization:

Integrated dual-microphone Beamforming ENC (ambient noise reduction), supports AI call noise reduction algorithm to improve speech clarity.

Supports hybrid active noise reduction (Hybrid ANC), and feedforward/feedback noise reduction mode can be configured.

Low power design:

It adopts ultra-low power architecture, supports Bluetooth dual-mode (classic Bluetooth + BLE) connection, and the standby current is as low as microampere level.

Integrated PMU power management unit for optimized battery life.

Peripherals and scalability:

Supports touch buttons, in-ear detection, GPIO wake-up, and adapts to a variety of interactive designs.

I ² C/SPI/UART interface is available for easy connection of sensors or external devices.

Application scenarios of BT8969B5

TWS Headphones: Supports HD audio, ANC noise cancellation, and low latency gaming mode.

Smart watch/bracelet: Can be paired with voice assistant to realize Bluetooth calls and music playback.

Bluetooth speaker: Supports multi-device connection, LE Audio broadcast mode (such as Auracast).
