STM32F401RCT6TR is based on the high-performance Arm® Cortex® -M4 32-bit RISC core operating at a frequency of up to 84 MHz. The Cortex®-M4 core features a Floating point unit (FPU) single precision which supports all Arm single-precision data-processing instructions and data types. It also implements a full set of DSP instructions and a memory protection unit (MPU) which enhances application security.

Specification Of STM32F401RCT6TR

Core: ARM Cortex M4

Program Memory Size: 256 kB

Data Bus Width: 32 bit

ADC Resolution: 12 bit

Maximum Clock Frequency: 84 MHz

Number of I/Os: 50 I/O

Data RAM Size: 64 kB

Supply Voltage - Min: 1.7 V

Supply Voltage - Max: 3.6 V

Minimum Operating Temperature: - 40 ℃

Maximum Operating Temperature: + 85 ℃

Data RAM Type: SRAM

Interface Type: I2C, I2S, SDIO, SPI, USART, USB

Number of ADC Channels: 16 Channel

Number of Timers/Counters: 8 Timer

Features Of STM32F401RCT6TR

Dynamic efficiency line with BAM (batch acquisition mode)

– 1.7 V to 3.6 V power supply

– -40 °C to 85/105/125 °C temperature range

Core: Arm® 32-bit Cortex®-M4 CPU with FPU, Adaptive real-time accelerator (ART Accelerator™) allowing 0-wait state execution from Flash memory, frequency up to 84 MHz, memory protection unit, 105 DMIPS/ 1.25 DMIPS/MHz (Dhrystone 2.1), and DSP instructions

Memories

– Up to 256 Kbytes of Flash memory

– 512 bytes of OTP memory

– Up to 64 Kbytes of SRAM

Clock, reset and supply management

– 1.7 V to 3.6 V application supply and I/Os

– POR, PDR, PVD and BOR

– 4-to-26 MHz crystal oscillator

– Internal 16 MHz factory-trimmed RC

– 32 kHz oscillator for RTC with calibration

– Internal 32 kHz RC with calibration

Power consumption

– Run: 128 µA/MHz (peripheral off)

– Stop (Flash in Stop mode, fast wakeup time): 42 µA typ @ 25 °C; 65 µA max @25 °C

– Stop (Flash in Deep power down mode, slow wakeup time): down to 10 µA typ@ 25 °C; 28 µA max @25 °C

– Standby: 2.4 µA @25 °C / 1.7 V without RTC; 12 µA @85 °C @1.7 V

– VBAT supply for RTC: 1 µA @25 °C

1×12-bit, 2.4 MSPS A/D converter: up to 16 channels

General-purpose DMA: 16-stream DMA controllers with FIFOs and burst support

Up to 81 I/O ports with interrupt capability

– All IO ports 5 V tolerant

– Up to 78 fast I/Os up to 42 MHz
