STM32F030F4P6TR is high-performance Arm® Cortex®-M0 32-bit RISC core operating at a 48 MHz frequency, high-speed embedded memories (up to 256 Kbytes of Flash memory and up to 32 Kbytes of SRAM), and an extensive range of enhanced peripherals and I/Os. All devices offer standard communication interfaces (up to two I2Cs, up to two SPIs and up to six USARTs), one 12-bit ADC, seven general purpose 16-bit timers and an advanced-control PWM timer.

Specification Of STM32F030F4P6TR

Core: ARM Cortex M0

Program Memory Size: 16 kB

Data Bus Width: 32 bit

ADC Resolution: 12 bit

Maximum Clock Frequency: 48 MHz

Number of I/Os: 15 I/O

Data RAM Size: 4 kB

Supply Voltage - Min: 2.4 V

Supply Voltage - Max: 3.6 V

Minimum Operating Temperature: - 40 ℃

Maximum Operating Temperature: + 85 ℃

Data RAM Type: SRAM

I/O Voltage: 2.4 V to 3.6 V

Interface Type: I2C, SPI, USART

Number of ADC Channels: 11 Channel

Features Of STM32F030F4P6TR

Core: Arm® 32-bit Cortex®-M0 CPU, frequency up to 48 MHz

Memories

– 16 to 256 Kbytes of Flash memory

– 4 to 32 Kbytes of SRAM with HW parity

CRC calculation unit

Reset and power management

– Digital & I/Os supply: VDD = 2.4 V to 3.6 V

– Analog supply: VDDA = VDD to 3.6 V

– Power-on/Power down reset (POR/PDR)

– Low power modes: Sleep, Stop, Standby

Clock management

– 4 to 32 MHz crystal oscillator

– 32 kHz oscillator for RTC with calibration

– Internal 8 MHz RC with x6 PLL option

– Internal 40 kHz RC oscillator

Up to 55 fast I/Os

– All mappable on external interrupt vectors

– Up to 55 I/Os with 5V tolerant capability

5-channel DMA controller

One 12-bit, 1.0 µs ADC (up to 16 channels)

– Conversion range: 0 to 3.6 V

– Separate analog supply: 2.4 V to 3.6 V

Calendar RTC with alarm and periodic wakeup from Stop/Standby

11 timers

– One 16-bit advanced-control timer for six-channel PWM output

– Up to seven 16-bit timers, with up to four IC/OC, OCN, usable for IR control decoding

– Independent and system watchdog timers

– SysTick timer

Communication interfaces

– Up to two I2C interfaces

– Fast Mode Plus (1 Mbit/s) support on one or two I/Fs, with 20 mA current sink

– SMBus/PMBus support (on single I/F)

– Up to six USARTs supporting master synchronous SPI and modem control; one with auto baud rate detection

– Up to two SPIs (18 Mbit/s) with 4 to 16 programmable bit frames
