The STM32F303CBT6 microcontroller is based on the high-performance Arm Cortex-M4 32-bit RISC core, with an operating frequency as high as 72 MHz, and is embedded with a floating-point unit (FPU), a memory protection unit (MPU), and an embedded tracking macro unit (ETM). The microcontroller integrates high-speed embedded memory (up to 128kbytes of flash and 32kbytes of SRAM) with a wide range of enhanced I/O and peripherals connected to two APB buses ‌.

Technical Specification

The main specifications of STM32F303CBT6 are as follows:

Core processor: ARM® Cortex®-M4

Kernel specification: 32-bit single-core

Speed: 72MHz

Connection capabilities: CANbus, I2C, IrDA, LINbus, SPI, UART/USART, USB

Peripheral devices: DMA, I2S, POR, PWM, WDT

I/O number: 37

Program storage capacity: 128KB (128K x 8)

Program memory type: Flash memory

EEPROM capacity: -

RAM size: 32K x 8

Voltage - Power Supply (Vcc/Vdd) : 2V to 3.6V

Data converter: A/D 15x12b D/A 2x12b

Oscillator type: Internal

Operating temperature: -40°C to 85°C (TA)

Installation type: Surface mount type

Device packaging: 48-LQFP (7x7)

Application field

The STM32F303CBT6 microcontroller is suitable for a variety of application fields, including:

Motor Drive & Control ‌ : Its dedicated motor control timer makes it excel in motor control applications.

Computers and Computer Peripherals ‌ : High performance signal processing capabilities make it suitable for tasks that require complex computing.

Communications and Networks ‌ : Rich communication interfaces make it widely used in communication devices.

Audio processing ‌ : High precision ADC and DAC make it perform well in audio processing.
