Trade Name:Voltage References
Brand:ADI
Particular Year:22+
Package:SOIC-8
Delivery Date:New and Original
Stock: 3000pcs
The ADR03ARZ is a high-performance, ultra-compact precision 2.5 V voltage reference featuring high accuracy, high stability and low power consumption for a wide range of precision analogue circuits and measurement systems.
ADR03ARZ Features
High Accuracy and Stability: Initial accuracy of ±0.2%, temperature coefficient of 10ppm/°C, low temperature drift and high output voltage stability.
Low Noise : Output voltage noise as low as 10μVp-p (0.1Hz to 10Hz) ensures a clean reference voltage in precision measurement applications.
High output current: Provides up to 10mA of output current without external buffers, simplifying circuit design.
Wide Operating Voltage Range: Supports a wide input voltage range of 4.5V to 36V, accommodating a wide range of power supply systems.
No external capacitors required: Built-in compensation capacitors reduce the number of external components and board space.
Overcurrent Protection and Thermal Shutdown Function: Built-in protection mechanism enhances system reliability under overload or fault conditions.
Compatibility : Pin compatible with the industry standard REF03 for easy replacement and upgrading.
ADR03ARZ Specifications
Output voltage : 2.5V (initial accuracy ±0.2%)
Temperature coefficient : 10ppm/°C
Operating voltage range: 4.5V to 36V
Output current: 10mA max.
Operating temperature range: -40°C to +125°C
Package: 8-pin SOIC
ADR03ARZ Applications
Precision data acquisition systems
High-resolution converters
Industrial process control systems
Precision instrumentation
Automatic battery monitoring
PCMCIA Cards
Model
Brand
Package
Quantity
Describe
ADI
SOT-23-3
26500
2.5V ultra-low power consumption, precision series mode reference voltage source
ADI
TSOT-23-6
22300
Precision, wide power supply range, high output drive, low noise reference
ADI
MSOP-8
3000
An 8ppm/°C, 5V reference voltage source certified for automotive applications
ADI
MSOP-8
3000
A reference voltage source of 8ppm/°C and 4.096V certified for automotive applications
ADI
MSOP-8
2500
An 8ppm/°C, 3.0V reference voltage source certified for automotive applications
ADI
MSOP-8
3000
An 8ppm/°C, 2.5V reference voltage source certified for automotive applications
ADI
SOT-23-6
3000
20ppm/°C precision, wide power supply range, high output drive, low noise reference
