Trade Name:Battery Charger
Brand:TI
Particular Year:22+
Package:WQFN-32
Delivery Date:New and Original
Stock: 9000pcs
The BQ25703ARSNR is a synchronous NVDC battery buck/boost charge controller that provides a high efficiency solution with a low component count for space-constrained multi-compound battery charging applications.
The NVDC-1 configuration stabilises the system voltage within the battery voltage range, but not below the minimum system voltage. The system continues to operate even when the battery is fully discharged or removed. When the load power exceeds the input source rating, the battery enters recharge mode and prevents the system from crashing.
The BQ25703ARSNR charges the battery from a variety of input sources such as USB adapters, high voltage USB PD sources, and conventional adapters.
During a charge, the charger sets the converter to buck, boost, or buck/boost configuration based on the input source and battery condition. The charger automatically switches between buck, boost, and buck/boost configurations without host control.
In the absence of an input source, the BQ25703ARSNR supports the On-the-Go (OTG) function with one to four batteries to generate 4.48V to 20.8V on VBUS. In OTG mode, the charger regulates the output voltage and output current.
The BQ25703ARSNR monitors adapter current, battery current, and system power. The flexibly programmable PROCHOT output goes directly to the CPU and can be derated as needed.
Features of the BQ25703ARSNR
Charges 1 to 4 batteries from a variety of input sources
3.5V to 24V input operating voltage
Supports USB 2.0, USB 3.0, USB 3.1 (Type-C) and USB_PD input current settings
Seamless transition between buck and boost operation
Provides input current and voltage regulation (IDPM and VDPM) to prevent power supply overloads
Power/current monitor for CPU throttling
Integrated PROCHOT setting, IMVP8 compliant
Input and battery current monitors
System power monitor, IMVP8 compliant
Narrow VDC (NVDC) power path management
Instant start without battery or with deeply discharged battery
Battery recharges the system when the adapter is full
Power USB port from battery (USB OTG)
Output 4.48V to 20.8V USB PD compatible
Output current limit up to 6.35A
Programmable switching frequency of 800kHz or 1.2MHz for 1µH to 3.3µH inductors
Flexible system configuration via host control interface
I2C (bq25703A) port for optimised system performance and status reporting
Hardware pin to set input current limits without EC control
Integrated ADC monitors voltage, current, and power
Highly accurate regulation and monitoring
±0.5% charge voltage regulation
±2% input/charge current regulation
±2% input/charge current monitoring
±5% power monitor
Safety
Thermal shutdown
Input, System, Battery Overvoltage Protection
MOSFET Inductive Overcurrent Protection
Low battery quiescent current
Input current optimiser (ICO) for maximum input power
Charge any battery chemistry: Li+, LiFePO4, NiCd, NiMH, Lead Acid
Package: 32-pin 4 x 4 WQFN
Applications for the BQ25703ARSNR
- Drones, Bluetooth speakers, IP cameras, detachable computers, tablets and mobile power supplies
- Industrial and medical equipment
- Portable devices with rechargeable batteries
Model
Brand
Package
Quantity
Describe
TI
WQFN-28
9000
SMBus 1- to 4-Cell Step-Down Battery Charge Controller with Hybrid Boost Mode Support
TI
TSSOP-8
20000
Switching Mode Multi-Compound Battery Charger with Peak Voltage Detection Terminal
TI
WQFN-28
16000
SMBus 1- to 4-Cell Step-Down Battery Charge Controller Supporting Hybrid Boost and Battery Boost Modes
Renesas
TQFN-32
4500
Booster battery charger with SMBus interface for universal 30V and USB PD EPR
Renesas
TQFN-32
3000
Buck - Boost configurable battery charger with SMBus interface and USB power supply
