DZ540N22K: 50 mm, single rectifier diode module, voltage 2200 V, with pressure contact technology

Model: DZ540N22K

Voltage: 2200V

Current: 540A

Type: Diode module

DZ540N22K - 50mm, Single Rectifier Diode Power Module, Voltage 2200V, Current 540A, with pressure contact technology, phase control using isolated copper base plate.

DZ540N22K Specifications:

Voltage - DC Reverse (Vr) (max): 2200 V

Current - Average Rectification (Io): 732A

Voltage - Forward (Vf) at different If: 1.64 V @ 2200 A

Speed: Standard Recovery >500ns, > 200mA (Io)

Current at varying Vr - reverse leakage: 40 mA @ 2200 V

Mounting Type: Chassis Mount

Package/Housing: Module

Supplier Device Package: Module

Operating Temperature - Junction: -40°C ~ 150°C

DZ540N22K Product Features:

Pressure contact technology for high reliability

Industry standard package

Electrically insulated backplane

Short-circuit in case of failure

Maximum ruggedness
