DDB2U40N12W1RF: 120 V, 40A, EasyBRIDGE CoolSiC™ Diode Module

The DDB2U40N12W1RF is a 1200 V, 40 A, EasyBRIDGE 1 diode bridge module with CoolSiC™ Schottky diode, PressFIT contact technology and NTC.

DDB2U40N12W1RF Specifications:

Series: CoolSiC™

Diode Type: Single Phase

Technology: Silicon Carbide Schottky

Voltage - Peak Reverse (Max): 1.2 kV

Current - Average Rectified (Io): 40 A

Voltage - Forward (Vf) at varying If: 1.85 V @ 40 A

Current - reverse leakage at varying Vr: 116 µA @ 1200 V

Operating Temperature: -40°C ~ 150°C (TJ)

Mounting Type: Chassis Mount

Package/Housing: Module

Supplier Device Package: AG-EASY1B-1

DDB2U40N12W1RF Feature Overview:

Features best-in-class Gen 5 SiC Schottky diode technology

Optimal pinouts

PressFIT technology

Broadest Easy product portfolio

Latest generation SiC diodes enable highly efficient DCDC subsystems

High power density and compact design

Optimised performance for fast DC charging

Easy design and high density
