Service Telephone:86-755-83294757
Trade Name:HDMI Transmitter
Brand:ADI
Particular Year:25+
Package:LQFP-64
Delivery Date:New and Original
Stock: 25000pcs
The ADV7513BSWZ is a 165 MHz High-Definition Multimedia Interface (HDMI®) transmitter especially suited for DVD players/recorders, digital set-top boxes, AV receivers, game consoles, and personal computers.
This digital video interface includes an HDMI v1.4/DVI v1.0 compatible transmitter that supports all HDTV formats. In addition to HDMI v1.4-specific features including 3D video, the ADV7513 supports x.v.Color™, High Bit Rate (HBR) audio, and programmable Auxiliary Video Information (AVI) InfoFrame features. The ADV7513 has built-in HDCP support for secure transmission of protected content as defined by the HDCP v1.4 protocol.
The ADV7513 supports both S/PDIF and 8-channel I2S audio formats. The high-fidelity 8-channel I2S interface can transmit stereo or 7.1-channel surround sound audio up to 768 kHz, while the S/PDIF interface can transmit compressed audio including Dolby® Digital, DTS®, and THX®. The ADV7513 is manufactured using an advanced CMOS process, and is available in a 64-pin surface-mount plastic-coated LQFP package (with exposed pads). It is rated over the -25°C to +85°C temperature range.
ADV7513BSWZ Features
Integrated HDMI v.1.4 features including 3D video support
165 MHz frequency support for all video formats up to 1080p and UXGA
Supports full audio metadata packet transmission
3D video ready
Programmable bi-directional colour space converter
Standard S/PDIF support for stereo linear pulse code modulation (LPCM) or compressed audio up to 192 kHz
High bit rate (HBR) audio
I2C and Hot Plug™ Detect (HPD) I/O with 5 V tolerance, no additional devices required
No audio master clock required to support S/PDIF and I2S
ADV7513BSWZ Applications
Game consoles
Personal computers
DVD players/recorders
Digital set-top boxes
Video and audio receivers
Model
Brand
Package
Quantity
Describe
A: all online goods on the shelves can be ordered online, but considering the large liquidity of spot inventory, it is not possible to achieve 100% accuracy at present. In case of any abnormality, you can contact our company online and give the corresponding solution.
A: our self-supporting products are from cooperative domestic and foreign original factories or authorized agents, and the source can be traced to ensure the original and authentic products.
A: at present, our self-employed brands TI,ST,ADI,NXP,LATTICE,CYPRESS,INFINEON,XILINX and other first-line brands. Other channels are the original factory and agency channels. If necessary, we can communicate and confirm according to the specific brand and model.
A: You can inquire through the website, or by phone and email.
A: the delivery date is marked in most commodity information. You can estimate the delivery time of the commodity according to the delivery date. The specific arrival time depends on the warehouse where the commodity is located and the logistics mode you choose.
A: you can issue ordinary invoices for individual users or special VAT invoices for enterprise users.
The full name of Analog Devices is Analog Devices, Inc. (ADI). As an outstanding supplier specializing in semiconductor sensors and signal processing ICs, adi regards innovation, performance and excellence as the cultural pillars of the company and ha…
AD5726YRSZ-1500
The AD5726YRSZ-1500 is a four-channel, 12-bit, serial input, voltage-output digital-to-analog converter (DAC) manufactured using ADIs iCMOS process technology, ensuring monotonicity with a maximum integrated nonlinearity (INL) error of 1 LSB. This dev…AD5696ACPZ
The AD5696ACPZ is a low-power, four-channel, 16-bit buffered voltage output DAC, belonging to the nanoDAC+™ series. This device is equipped with an internal gain selection pin, and its full-scale output is 0V to VREF (gain = 1) or 0V to 2VREF (gain =…AD5044BRUZ
The AD5044BRUZ is a low-power, four-channel 14-bit buffered voltage output nanoDAC digital-to-analog converter produced by Analog Devices (ADI), featuring a relative accuracy characteristic of 1 LSB INL (integrated nonlinearity) and 1 LSB DNL (differe…AD5694ARUZ
The AD5694ARUZ digital-to-analog converter belongs to the nanoDAC+ series and is a low-power, four-channel, 16-bit buffered voltage output DAC. This device is equipped with an internal gain selection pin, and its full-scale output is 0V to VREF (gain …AD9714BCPZ
The AD9714BCPZ is a dual-channel, 8-bit low-power digital-to-analog converter (DAC) produced by Analog Devices (ADI), supporting a maximum sampling rate of 125 MSPS and featuring an LFCSP-40 package. The following are its core features:Power consumpti…AD7243BRZ
The AD7243BRZ is a complete 12-bit voltage output digital-to-analog converter, integrating an output amplifier and Zener reference voltage source on a single CMOS chip. All rated performance can be achieved without external adjustment. The following a…Contact Number:86-755-83294757
