Commodity Model:RAA489400A3GNP

Trade Name:USB Controller

Brand:Renesas

Particular Year:25+

Package:QFN-32

Delivery Date:New and Original

Stock: 2000pcs

Quantity:
Online Inquiry

Contacts:

E-Mail:

Contact Number:

Corporate Name:

Product Parameters

Manufacturer
Renesas
Model
RAA489400A3GNP
Package
QFN-32
Describe
USB Type-C Port Controller

Product Description

RAA489400A3GNP is a USB Type-C® port controller designed under the USB Type-C Port Controller Interface Specification, USB Type-C Cable and Connector Specification, and USB Power Delivery (USB PD) Specification. A single USB Type-C Port Manager can be combined with multiple RAA489400A3GNP devices to implement all USB PD functions, such as power negotiation and Alternate Mode support, for multiple USB Type-C ports. RAA489400A3GNP supports a 60V absolute maximum rating for both a VBUS voltage monitor (with relevant pin functions) and CC1/CC2, enabling a system capable of providing Extended Power Range (EPR) operation up to 240W/48V.


Feature Of RAA489400A3GNP

USB Type-C® Port Controller (TCPC) with integrated TCPC PHY, CC-Logic

Supports USB Type-C Port Controller Interface (TCPCi) Revision 2.0 with Extended Power Range (EPR)

Supports USB Power Delivery (USB PD) Revision 3.1 (Certified Silicon TID: 10147)

Supports USB Type-C Release 2.1

CC1/CC2 absolute maximum rating: 60V

Dead battery Rd support

SMBus/I2C slave target with ALERT# for USB Type-C Port Manager (TCPM)

Integrated VCONN MUX

RDSON: 500mΩ for 5V VCONN power

VCONN protections: OCP/OVP/UVP/OTP/RVP

VCONN Overcurrent threshold options: 600mA (default), 400mA, and 800mA

48V tolerance for VBUS based on USB PD Revision 3.1 EPR

Recommended operating condition: 55V (maximum)

Absolute Maximum Rating: 60V

VBUS discharge

VBUS protections: OCP/OVP/UVP/RVP

VBUS-CC short-circuit protection

VBUS source and sink power path gate drivers with external NFET

OCP# fault signal output

Sink Fast Role Swap (FRS) support

4-channel GPIO (such as VBUS source gate enable control, VBUS sink gate enable control with VBUS power switch, overcurrent input from external power switch)

PROCHOT# output for VBUS source adapter disconnection and FRS Event notification

Internal sink path discharge

Integrated 3.3V LDO for TCPM power supply in dead battery scenarios

ADC for VBUS voltage and current measurement

VSYS33 (main power supply): Typical 3.3V

Package: 32-pin FCQFN, 3.0mm × 5.0mm


Applications

General purpose application with high power up to 240W

Battery powered mobile devices

Electric bikes, robots, and drones

Power tools, battery packs

Home appliances such as vacuum cleaners

Notebooks, tables, power banks, and desktop PCs


Associated Products

Model

Brand

Package

Quantity

Describe

CY7C65223T-24LQXST

INFINEON

QFN-24

1000

Full-Speed USB-UART Automotive single-channel bridge controller

CYPD727268LQXQT

Cypress

VQFN-68

1000

EZ-PD™ CCG7DC Dual-Port USB-C Power Delivery and DC-DC Controller

CY7C65211A24LQXST

INFINEON

QFN-24

2000

USB Bridge, USB to I2C USB 2.0 UART Interface

CY7C6521024LQXST

INFINEON

QFN-24

2000

USB Controller USB 2.0 GPIO, I2C Interface
