For picture reference, please see the specifications
< >

Commodity Model:MK22FN128VLL10

Trade Name:ARM Microcontrollers - MCU

Brand:NXP

Particular Year:25+

Package:LQFP-100

Delivery Date:New and Original

Stock: 5000pcs

Quantity:
Online Inquiry

Contacts:

E-Mail:

Contact Number:

Corporate Name:

Product Parameters

Manufacturer
NXP
Model
MK22FN128VLL10
Package
LQFP-100
Describe
ARM Microcontrollers - MCU K22F 128R Senna

Product Description

The MK22FN128VLL10 is a 32-bit ARM Cortex-M4 microcontroller belonging to the Kinetis K22 family for applications requiring low power consumption, high performance and high integration, such as industrial control, consumer electronics and IoT devices.


The Kinetis K22 product family is optimised for cost-sensitive applications requiring low power consumption, USB connectivity, high peripheral integration, and floating-point unit processing efficiency. These devices share the full support and scalability of the Kinetis family. The product offers

- Operating power as low as 120 μA/MHz. static power as low as 2.6 μA (full state hold and 6 μs wake-up). Lowest static mode power consumption down to 120 nA.

- USB LS/FS OTG 2.0 with embedded 3.3 V, USB FS device without crystal.


MK22FN128VLL10 Product Attributes:

Product Category: ARM Microcontrollers - MCUs

Family: K22_100

Mounting Style: SMD/SMT

Package / Case: LQFP-100

Core: ARM Cortex M4

Programme memory size: 128 kB

Data bus width: 32 bit/16 bit

ADC resolution: 16 bit

Maximum clock frequency: 100 MHz

Number of inputs/outputs: 66 I/Os

Data RAM size: 24 kB

Supply voltage - min: 1.71 V

Supply voltage - max: 3.6 V

Minimum operating temperature: - 40 C

Maximum operating temperature: + 105 C

Analogue supply voltage: 1.71 V to 3.6 V

Data Ram type: SRAM

I/O Voltage: 1.71 V to 3.6 V

Interface type: DSPI, I2C, I2S, LPUART, USB

Humidity Sensitivity: Yes

Number of ADC channels: 2 Channel

Number of Timers/Counters: 3 Timer

Processor family: K22F

Programme memory type: Flash

Trade Name: Kinetis
