The S6J32EELTPSC20000 is a 32-bit automotive grade microcontroller, belonging to the Traveo series, based on the ARM Cortex-R5F core, with up to 240MHz, 4.17MB Flash and 2.125MB RAM. It is designed for high reliability scenarios, such as automotive electronics, industrial control, etc., and is compliant with AEC-Q100 Grade 1 standards. Grade 1 standard, supporting complex real-time control and multi-tasking.

Product Attributes--S6J32EELTPSC20000

Core Processor: ARM® Cortex®-R5F

Core specification: 32-bit

Speed: 240MHz

Connectivity: CANbus, CSIO, Ethernet, I2C, LINbus, SPI, UART/USART

Peripherals: DMA, I2S, LVD, POR, PWM, WDT

Number of I/O 128

Program memory capacity: 4.171875MB (4.171875M x 8)

Programme memory type: Flash

RAM Size: 2.125M x 8

Voltage - Supply (Vcc/Vdd): 1.1V ~ 5.5V

Data Converter: A/D 50x12b

Oscillator Type: Internal

Operating Temperature: -40°C ~ 105°C (TA)

Mounting Type: Surface Mount

Supplier Device Package: 216-TEQFP (24x24)

Package/Housing: 216-LQFP bare pads
