The STM32F103ZEH6 performance line family integrates a high-performance Arm® Cortex®-M3 32-bit RISC core operating at 72 MHz with high-speed embedded memory (up to 512 KB for Flash and 64 KB for SRAM) and a large number of enhanced I/Os and peripherals connected to two APB buses. All devices offer three 12-bit ADCs, four general-purpose 16-bit timers and two PWM timers, as well as standard and advanced communication interfaces: up to two I2C, three SPI, two I2S, one SDIO, five USART, one USB and one CAN.

The STM32F103ZEH6 high-density performance line family operates over the -40 to +105°C temperature range and is powered from a 2.0 to 3.6V supply. A comprehensive set of power saving modes allows the design of low power applications.

Features

Up to 1MB program memory size

32-bit data bus width

12-bit ADC resolution

Maximum clock frequency of up to 72MHz

Up to 112 I/Os

Up to 96KB data RAM size

2V to 3.6V operating supply voltage

These features make the STM32F103ZEH6 high-density performance line microcontroller family suitable for a variety of applications such as motor drives, application control, medical and handheld devices, PC and gaming peripherals, GPS platforms, industrial applications, PLCs, inverters, printers, scanners, video intercom for alarm systems and HVAC.

• 1.Is the inventory and price seen on the platform accurate?

  A: all online goods on the shelves can be ordered online, but considering the large liquidity of spot inventory, it is not possible to achieve 100% accuracy at present. In case of any abnormality, you can contact our company online and give the corresponding solution.

• 2.Are all our products genuine?

  A: our self-supporting products are from cooperative domestic and foreign original factories or authorized agents, and the source can be traced to ensure the original and authentic products.

• 3.Can you provide the qualification certificate of the original factory or agent?

  A: at present, our self-employed brands TI，ST，ADI，NXP，LATTICE，CYPRESS，INFINEON，XILINX and other first-line brands. Other channels are the original factory and agency channels. If necessary, we can communicate and confirm according to the specific brand and model.

• 4.Can I make an inquiry through the company's website?

  A: You can inquire through the website, or by phone and email.

• 5.When can I deliver the goods after placing an order? How long will it take to get there?

  A: the delivery date is marked in most commodity information. You can estimate the delivery time of the commodity according to the delivery date. The specific arrival time depends on the warehouse where the commodity is located and the logistics mode you choose.

• 6.Can the company issue an invoice?

  A: you can issue ordinary invoices for individual users or special VAT invoices for enterprise users.
