EEEHC1C101XP Product Attributes:

Manufacturer: Panasonic Electronic Components

Series: HC

Capacitance 100: µF

Tolerance: ±20%

Voltage - Rated: 16 V

ESR (Equivalent Series Resistance): -

Service life at different temperatures: 3000 hours at 105°C

Operating temperature: -40°C ~ 105°C

Polarisation: Polarisation

Class: AEC-Q200

Application: Automotive grade

Ripple current at different low frequencies: 81 mA @ 120 Hz

Ripple current at different high frequencies: 137.7 mA @ 10 kHz

Lead spacing: -

Size / Dimension: 0.248" diameter (6.30mm)

Height - Mount (max): 0.303" (7.70mm)

Surface Mount Pad Size: 0.260" L x 0.260" W (6.60mm x 6.60mm)

Mounting Type: Surface Mount Type

Package / Housing: Radial, Can - SMD

Basic Product Number: EEE-HC

Panasonic HC series SMD aluminium electrolytic capacitors offer a functional life of 3000h to 5000h at +105°C, comply with AEC-Q200 and are RoHS compliant. Vibration-proof products are available in 08mm and larger sizes. Panasonic's HC series are available in nominal voltage ranges from 6.3VDC to 50VDC, nominal capacitance ranges from 1μF to 1000μF, capacitance tolerance of ±20% (120Hz/+20°C) and DC leakage current I<0.01CV or 3 (μA) after 2 minutes (whichever is greater).
