Service Telephone:86-755-83294757
Trade Name:L6385D013TR
Data Manual:L6385D013TR.pdf
Brand:ST
Particular Year:L6385D013TR
Package:SOP8
Delivery Date:New and Original
Stock: 6785pcs
The L6385 is an high-voltage device, manufactured with the BCD"OFF-LINE" technology. It has a Driver structure that enables to drive independent referenced N Channel Power MOS or IGBT. The Upper (Floating) Section is enabled to work with voltage Rail up to 600V. The Logic Inputs are CMOS/TTL compatible for ease of interfacing with controlling devices.
Specifications
Drive configuration half bridge
Channel type Stand-alone
Number of drivers 2
Gate type IGBT, N-channel MOSFET
Voltage - Supply 17V (max)
Logic Voltage - VIL, VIH 1.5V, 3.6V
Current - Peak Output (Pour In, Pull Out) 400mA, 650mA
Input Type Inverted
High Side Voltage - Maximum (Bootstrap) 600 V
Rise/Fall Time (typical) 50ns, 30ns
Operating Temperature -40°C ~ 150°C (TJ)
Mounting Type Surface Mount Type
Package/Case 8-SOIC (0.154", 3.90mm wide)
Supplier Device Package 8-SOIC
