LP5813CDRRR

Product type: RGB LED driver

Type: DC DC voltage regulator

Topology: Boost voltage

Internal switch: Yes

Output number: 1

Voltage - power supply (min) : 500mV

Voltage - Power supply (Max) : 5.5V

Voltage - output: 3V ~ 5.5V

Current - Output/channel: 50mA

Frequency: 500kHz, 1MHz

Dimming: Analog, PWM

Application: General purpose

Operating temperature: -40°C ~ 85°C (TA)

Grade: -

Qualification: -

Mounting type: Surface mount type

Package/housing: 12-WFDFN bare pad

Supplier Package: 12-WSON (3x3)

Instructions

The LP5813CDRRR is a synchronous boost 4 × 3 matrix RGB LED driver with autonomous animation engine control. The device is ideal for battery-powered applications that support input voltage ranges from 0.5V to 5.5V, and has an ultra-low normal operating current of 0.4mA (typical value) when the LED is lit.

The LP5813CDRRR device is suitable for LED animation and indication of:

• Portable and wearable electronics - Earplugs and charging cases, e-cigarettes, smartwatches

• Gaming and home entertainment - smart speakers, RGB mouse, VR headset and controller

• Internet of Things (IOT) - electronic tags, visual doorbells

• Network - router, access point

• Industrial HMI - electric vehicle charger, factory automation
