BCM88790CB0KFSBG - Scalable Fabric Element 9.6Tbps Self-Routing Switching Element

BCM88790CB0KFSBG - Product Description:

BCM88790CB0KFSBG is the fifth generation in the StrataDNX™ product line of Fabric Element (FE) devices, and is a self-routing cell-based switching element. This device enables BCM88690 switch-based systems to build flexible networking platforms providing user bandwidth over 2400 Tbps. The BCM88790 provides a complete solution for switching fabric, traffic management, packet processing, and network interfaces. Switching platforms can scale up to 24,000 100GbE ports or 6,000 400GbE ports.

BCM88790CB0KFSBG - Key Features:

Self-routing device with dynamic load balancing

Support for single-stage and three-stage fabric configurations

Interconnects up to 1K of BCM88690 devices in a system

Switches destination-routed and source-routed data cells and control cells

Supports fabric multicast and multicast load balancing

Support for three pipes with flexible allocation,

e.g., TDM/OTN - Unicast Data - Multicast Data

Configurable SerDes rate

Automatic fault detection

Scheduled device removal and device insertion without cell loss

Parallel local processor interface using two lanes PCIe Gen3 for configuration, monitoring, and statistics

Option for Broadcom Serial Control (BSC)

In-band management and configuration

Built-in SerDes FEC and PRBS
