Trade Name:Analog switch
Brand:TI
Particular Year:24+
Package:16-TSSOP
Delivery Date:New and original
Stock: 2000pcs
The TMUX6136PWR is a complementary metal-oxide-semiconductor (CMOS) analog switch with two independently selectable SPDT switches.
The device operates with dual (±5V to ±16.5V), single (10V to 16.5V) or asymmetrical power supplies. Digital selection pins (SELx) have transistor-to-transistor logic (TTL) compatible thresholds that ensure TTL/CMOS logic compatibility.
Specifications
Switching circuit: SPDT
Multiplexer/demultiplexer circuit: 2:1
Circuit number: 2
On-resistance (Max.) : 135 ohms
Channel-to-channel matching (ΔRon) : 2.5 ohms
Voltage - power supply, single (V+) : 10V ~ 16.5V
Voltage - power supply, double (V±) : ±5V ~ 16.5V
Switching time (Ton, Toff) (maximum) : -
-3db Bandwidth: 670MHz
Charge injection: -0.4pC
Channel capacitance (CS(off), CD(off)) : 2.4pF
Current - leakage (IS(off)) (Max) : 50pA
Crosstalk: -105dB to -92dB@1MHz
Operating temperature: -40°C ~ 125°C (TA)
Mounting type: Surface mount type
Package/housing: 16-TSSOP (0.173", 4.40mm wide)
Supplier device package: 16-TSSOP
Basic product number: TMUX6136
