Ideal for space-critical applications, the LM4040CIM3X-2.5 precision voltage references are available in a small SOT-23 surface mount package.The advanced design of the LM4040-N eliminates the need for external stabilisation capacitors while ensuring stability under any capacitive load, making the LM4040-N very easy to use.

Features

- LM4040-N-Q1 meets AEC Q-100 requirements for automotive applications

- Extended Class 1: -40°C to +125°C, TA

- Industrial Grade 3: -40°C to +85°C, TA

- Small package: SOT-23, TO-92, and SC70

- No output capacitors required

- Capable of accepting capacitive loads

- Fixed reverse breakdown voltages of 2.048V, 2.5V, 3V, 4.096V, 5V, 8.192V, and 10V

- Key Specifications (2.5V LM4040-N)

- Output voltage tolerance (Class A, 25°C): ±0.1% (max)

- Low output noise (10Hz to 10kHz): 35μVrms (typical)

- Wide operating current range: 60μA to 15mA

- Industrial temperature range: -40°C to +85°C

- Extended temperature range: -40°C to +125°C

- Extended temperature range: -40°C to +125°C Low temperature coefficient: 100ppm/°C (maximum)

Applications

- Portable, battery-powered equipment

- Data acquisition systems

- Instrumentation

- Process control

- Power management

- Product Testing

- Automotive

- Precision Audio Components
