For picture reference, please see the specifications
< >

Commodity Model:MC56F8323VFBER

Trade Name:MC56F8323VFBER

Brand:NXP

Particular Year:24+

Package:LQFP48

Delivery Date:New and Original

Stock: 1210pcs

Quantity:
Online Inquiry

Contacts:

E-Mail:

Contact Number:

Corporate Name:

Product Parameters

Manufacturer
NXP
Model
MC56F8323VFBER
Package
LQFP48
Describe
56800E 56F8xxx Microcontroller IC 16-bit 60MHz 32KB (16K x 16) Flash 64-LQFP (10x10)

Product Description

The MC56F8323VFBER is a family of Digital Signal Controllers (DSC) based on the 56800E core, which provides both Digital Signal Processor (DSP) processing capability and microcontroller functionality on a single chip.


It features 60 MIPS performance (at 60 MHz) with 32 KB of on-chip flash memory and a comprehensive set of peripherals. It extends the functionality of the 56F8322/8122 by adding analogue-to-digital converter (ADC) inputs and timer input/output pins, among other enhancements.


Product Attributes

Product Category: Digital Signal Processors and Controllers - DSP, DSC

Products: DSCs

Core: 56800E

Number of Cores: 1 Core

Maximum clock frequency: 60 MHz

Package / Case: QFP-64

Programme memory size: 32 kB

Data RAM size: 8 kB

Operating supply voltage: 3.3 V

Series: 56F832xx

Mounting style: SMD/SMT

Minimum operating temperature: - 40 C

Maximum operating temperature: + 105 C

Qualification: AEC-Q100

ADC resolution: 12 bit

Data bus width: 16 bit

Height: 1.45 mm

Interface type: CAN, SCI, SPI

Length: 10 mm

Humidity sensitivity: Yes

Number of inputs/outputs: 27 I/Os

Number of timers/counters: 2 Timer

Product Type: DSP - Digital Signal Processors & Controllers

Programme memory type: Flash

Factory Package Quantity: 800

Sub Category: Embedded Processors & Controllers

Supply Voltage - Max: 3.6 V

Supply Voltage - Min: 3 V

Watchdog Timer: Watchdog Timer

Width: 10 mm

Unit Weight: 346.550 mg
