For picture reference, please see the specifications
< >

Commodity Model:MC56F8357MPYE

Trade Name:MC56F8357MPYE

Brand:NXP

Particular Year:24+

Package:LQFP160

Delivery Date:New and Original

Stock: 5000pcs

Quantity:
Online Inquiry

Contacts:

E-Mail:

Contact Number:

Corporate Name:

Product Parameters

Manufacturer
NXP
Model
MC56F8357MPYE
Package
LQFP160
Describe
Digital Signal Processors and Controllers - DSP, DSC 16-bit DSC, 56800E Core, 256KB Flash, 60MHz, QFP160

Product Description

The NXP MC56F8357MPYE digital signal controllers belong to the DSC family based on the 56800E core. They have both digital signal processor (DSP) processing power and microcontroller functions on a single chip with a flexible set of peripherals.

• Features such as on-chip integration and ease of implementation help accelerate development, reduce component count, and significantly lower system cost.

• Twice as much program flash, data memory and boot flash as the 56F8345/8145 while providing full pin compatibility.

• Includes external memory interface

• Simplifies design while facilitating compliance with safety regulations.

• Powerful development tools to simplify and accelerate time-to-market


Product Specifications

Core Processor: 56800E

Core specification: 16-bit

Speed: 60MHz

Connectivity: CANbus, EBI/EMI, SCI, SPI

Peripherals: POR, PWM, Temperature Sensor, WDT

Number of I/O: 76

Program memory capacity: 256KB (128K x 16)

Program Memory Type: Flash

RAM Size: 10K x 16

Voltage - Supply (Vcc/Vdd): 2.25V ~ 3.6V

Data Converter: A/D 16x12b

Oscillator Type: External

Operating Temperature: -40°C ~ 125°C (TA)

Mounting Type: Surface Mount

Supplier Device Package: 160-LQFP (24x24)

Package/Housing: 160-LQFP
